前言

上一篇博客：ros机器人编程实践（15.2）- 使用科大讯飞语音控制turtlebot导航 在上一篇博客中我们已经实现了语音控制turtlebot导航，这一节尝试实现turtlebot语音播报。

科大讯飞的语音合成测试

安装教程在这:传送门

rosrun xfei_asr tts_subscribe_speak
rostopic pub xfwords std_msgs/String "你好，世界！"

    根据rostopic pub xfwords std_msgs/String "你好，世界！"我们可以看出语音合成节点接收的话题是xfwords，话题的消息类型是String。

修改语音导航脚本

sudo gedit ~/wanderbot_ws/src/wanderbot/src/voice_contrl.py

#!/usr/bin/env python
# -*- coding: UTF-8 -*-
import rospy
import actionlib
import roslib;
import rospy
from std_msgs.msg import String

from move_base_msgs.msg import MoveBaseAction, MoveBaseGoal


waypoints = [  # <1>
    [(1.522, 0.444, 0.0), (0.0, 0.0, -0.519, 0.85)],
    [(-2.0432, -0.439, 0.0), (0.0, 0.0, -0.559, 0.82902)]
]


def goal_pose(pose):  # <2>
    goal_pose = MoveBaseGoal()
    goal_pose.target_pose.header.frame_id = 'map'
    goal_pose.target_pose.pose.position.x = pose[0][0]
    goal_pose.target_pose.pose.position.y = pose[0][1]
    goal_pose.target_pose.pose.position.z = pose[0][2]
    goal_pose.target_pose.pose.orientation.x = pose[1][0]
    goal_pose.target_pose.pose.orientation.y = pose[1][1]
    goal_pose.target_pose.pose.orientation.z = pose[1][2]
    goal_pose.target_pose.pose.orientation.w = pose[1][3]

    return goal_pose

def callback(msg):
	print msg.data
        pub2 = rospy.Publisher('xfwords',String,queue_size = 1)
	if msg.data.find('一') > -1:
            pose = waypoints[0]
            print '主人，准备出发一号站点请系好安全带！'
            pub2.publish('准备出发一号站点请系好安全带！')
            pub2.publish('准备出发一号站点请系好安全带！')
        elif msg.data.find('三') > -1:
            pose = waypoints[1]
            print '主人，准备出发三号站点请系好安全带！'
            pub2.publish('准备出发三号站点请系好安全带！')
            pub2.publish('准备出发三号站点请系好安全带！')
        else:
            return;

        client = actionlib.SimpleActionClient('move_base', MoveBaseAction)  # <3>
        client.wait_for_server()

        print("goal:x=%f y=%f"%(pose[0][0],pose[0][1]))
        goal = goal_pose(pose)
        client.send_goal(goal)
        client.wait_for_result()
	if msg.data.find('一') > -1:
            print '主人，一号站点已经到啦！'
            pub2.publish('主人，一号站点已经到啦！')
        elif msg.data.find('三') > -1:
            print '主人，三号站点已经到啦！'
            pub2.publish('主人，三号站点已经到啦！')


if __name__ == '__main__':

    rospy.init_node('message_publisher')

    pub=rospy.Publisher('voiceWakeup',String,queue_size = 1)

    rospy.sleep(1)
    pub.publish('wake up')

    sub = rospy.Subscriber('voiceWords', String,callback)
    rospy.spin()

  代码很简单，就不多解释了。然后我们昨天写的持续唤醒脚本有点小问题，他在不停的登出登录，这样很占网络资源，我们修改下成一次登录。（如果你不想改也无所谓）

sudo gedit ~/wanderbot_ws/src/robot_voice/src/iat_publish.py

  在前面加上登录的标志位：

int login_flag = 0;//在前面加上登录的标志位

  如图：     将while(ros::ok())中修改为：

        // 语音识别唤醒
        if (wakeupFlag){
            ROS_INFO("Wakeup...");
            int ret = MSP_SUCCESS;
            if(login_flag == 0)
	    {
            	const char* login_params = "appid = 5e608f55, work_dir = .";



            	ret = MSPLogin(NULL, NULL, login_params);
            	if(MSP_SUCCESS != ret){
                	MSPLogout();
                	printf("MSPLogin failed , Error code %d.\n",ret);
            	}else
                {login_flag = 1;}
            }

            const char* session_begin_params =
                "sub = iat, domain = iat, language = zh_cn, "
                "accent = mandarin, sample_rate = 16000, "
                "result_type = plain, result_encoding = utf8";

            printf("Demo recognizing the speech from microphone\n");
            printf("Speak in 10 seconds\n");

            demo_mic(session_begin_params);

            printf("10 sec passed\n");

            wakeupFlag=0;
            //MSPLogout();
        }

  如图：     大功告成了～

功能测试

启动仿真环境：

roslaunch turtlebot3_gazebo turtlebot3_world.launch

  启动rviz：

roslaunch turtlebot3_navigation turtlebot3_navigation.launch map_file:=$HOME/map.yaml

  启动语音检测脚本：

rosrun robot_voice iat_publish

  启动语音合成脚本：

rosrun xfei_asr tts_subscribe_speak

  启动语音控制导航脚本：

rosrun wanderbot voice_contrl.py

  后面三条rosrun可以改写成launch脚本，省的启动这么多～

cd ~/wanderbot_ws/src/wanderbot
mkdir launch
cd launch
gedit voiceContrlFunc.launch

  voiceContrlFunc.launch文件如下：

<launch>
  <node pkg="robot_voice" type="iat_publish" name="iat_publish"  output="screen">
  </node>
  <node pkg="xfei_asr" type="tts_subscribe_speak" name="tts_subscribe_speak"  output="screen">
  </node>
  <node pkg="wanderbot" type="voice_contrl.py" name="voice_contrl"  output="screen">
  </node>
</launch>

  然后启动语音控制如下即可：   启动仿真环境：

roslaunch turtlebot3_gazebo turtlebot3_world.launch

  启动rviz：

roslaunch turtlebot3_navigation turtlebot3_navigation.launch map_file:=$HOME/map.yaml

  启动导航功能：

roslaunch wanderbot voiceContrlFunc.launch

  好了，提示消息全在一个终端了：
