功能包下载链接:https://download.csdn.net/download/qq_42145185/12265062 启动命令:roslaunch face_tracker_pkg start_tracking.launch 核心检测代码:
/*
* This code will track the faces using ROS
*/
//ROS headers
#include <ros/ros.h>
#include <image_transport/image_transport.h>
#include <cv_bridge/cv_bridge.h>
#include <sensor_msgs/image_encodings.h>
//Open-CV headers
#include <opencv2/imgproc/imgproc.hpp>
#include <opencv2/highgui/highgui.hpp>
#include "opencv2/objdetect.hpp"
//Centroid message headers
#include <face_tracker_pkg/centroid.h>
//OpenCV window name
static const std::string OPENCV_WINDOW = "raw_image_window";
static const std::string OPENCV_WINDOW_1 = "face_detector";
using namespace std;
using namespace cv;
class Face_Detector
{
ros::NodeHandle nh_;
image_transport::ImageTransport it_;
image_transport::Subscriber image_sub_;
image_transport::Publisher image_pub_;
ros::Publisher face_centroid_pub;
face_tracker_pkg::centroid face_centroid;
string input_image_topic, output_image_topic, haar_file_face;
int face_tracking, display_original_image, display_tracking_image, center_offset, screenmaxx;
public:
Face_Detector()
: it_(nh_)
{
//Loading Default values 加载默认值
input_image_topic = "/usb_cam/image_raw";
output_image_topic = "/face_detector/raw_image";
haar_file_face = "/home/dobot/face_detect_ws/src/face_tracker_pkg/data/face.xml";
face_tracking = 1;
display_original_image = 1;
display_tracking_image = 1;
screenmaxx = 640;
center_offset = 100;
//Accessing parameters from track.yaml 从track.yaml访问参数
try{
nh_.getParam("image_input_topic", input_image_topic);
nh_.getParam("face_detected_image_topic", output_image_topic);
nh_.getParam("haar_file_face", haar_file_face);
nh_.getParam("face_tracking", face_tracking);
nh_.getParam("display_original_image", display_original_image);
nh_.getParam("display_tracking_image", display_tracking_image);
nh_.getParam("center_offset", center_offset);
nh_.getParam("screenmaxx", screenmaxx);
ROS_INFO("Successfully Loaded tracking parameters");
}
catch(int e)
{
ROS_WARN("Parameters are not properly loaded from file, loading defaults");
}
// Subscribe to input video feed and publish output video feed
//订阅输入视频提要并发布输出视频提要
image_sub_ = it_.subscribe(input_image_topic, 1,
&Face_Detector::imageCb, this);
image_pub_ = it_.advertise(output_image_topic, 1);
face_centroid_pub = nh_.advertise<face_tracker_pkg::centroid>("/face_centroid",10);
}
~Face_Detector()
{
if( display_original_image == 1 or display_tracking_image == 1)
cv::destroyWindow(OPENCV_WINDOW);
}
void imageCb(const sensor_msgs::ImageConstPtr& msg)
{
cv_bridge::CvImagePtr cv_ptr;
namespace enc = sensor_msgs::image_encodings;
try
{
cv_ptr = cv_bridge::toCvCopy(msg, sensor_msgs::image_encodings::BGR8);
}
catch (cv_bridge::Exception& e)
{
ROS_ERROR("cv_bridge exception: %s", e.what());
return;
}
string cascadeName = haar_file_face;
CascadeClassifier cascade;
if( !cascade.load( cascadeName ) )
{
cerr << "ERROR: Could not load classifier cascade" << endl;
}
if (display_original_image == 1){
imshow("Original Image", cv_ptr->image);
}
detectAndDraw( cv_ptr->image, cascade );
image_pub_.publish(cv_ptr->toImageMsg());
waitKey(30);
}
void detectAndDraw( Mat& img, CascadeClassifier& cascade)
{
double t = 0;
double scale = 1;
vector<Rect> faces, faces2;
const static Scalar colors[] =
{
Scalar(255,0,0),
Scalar(255,128,0),
Scalar(255,255,0),
Scalar(0,255,0),
Scalar(0,128,255),
Scalar(0,255,255),
Scalar(0,0,255),
Scalar(255,0,255)
};
Mat gray, smallImg;
cvtColor( img, gray, COLOR_BGR2GRAY );
double fx = 1 / scale ;
//缩小或者放大函数至某一个大小
resize( gray, smallImg, Size(), fx, fx, INTER_LINEAR );
//直方图均衡化,,用于提高图像的质量
equalizeHist( smallImg, smallImg );
//统计代码运行时间
t = (double)cvGetTickCount();
//人脸检测
cascade.detectMultiScale( smallImg, faces,
1.1, 15, 0
|CASCADE_SCALE_IMAGE,
Size(30, 30) );
t = (double)cvGetTickCount() - t;
for ( size_t i = 0; i < faces.size(); i++ )
{
Rect r = faces[i];
Mat smallImgROI;
vector<Rect> nestedObjects;
Point center;
Scalar color = colors[i%8];
int radius;
double aspect_ratio = (double)r.width/r.height;
if( 0.75 < aspect_ratio && aspect_ratio < 1.3 )
{
//cvRound对一个double型的数进行四舍五入,并返回一个整型数
center.x = cvRound((r.x + r.width*0.5)*scale);
center.y = cvRound((r.y + r.height*0.5)*scale);
radius = cvRound((r.width + r.height)*0.25*scale);
circle( img, center, radius, color, 3, 8, 0 );
face_centroid.x = center.x;
face_centroid.y = center.y;
//Publishing centroid of detected face 发布检测到的人脸的质心
face_centroid_pub.publish(face_centroid);
}
else
rectangle( img, cvPoint(cvRound(r.x*scale), cvRound(r.y*scale)),
cvPoint(cvRound((r.x + r.width-1)*scale), cvRound((r.y + r.height-1)*scale)),
color, 3, 8, 0);
}
//Adding lines and left | right sections 添加行和左| 正确的部分
Point pt1, pt2,pt3,pt4,pt5,pt6;
//Center line
pt1.x = screenmaxx / 2;
pt1.y = 0;
pt2.x = screenmaxx / 2;
pt2.y = 480;
//Left center threshold
pt3.x = (screenmaxx / 2) - center_offset;
pt3.y = 0;
pt4.x = (screenmaxx / 2) - center_offset;
pt4.y = 480;
//Right center threshold
pt5.x = (screenmaxx / 2) + center_offset;
pt5.y = 0;
pt6.x = (screenmaxx / 2) + center_offset;
pt6.y = 480;
line(img, pt1, pt2, Scalar(0, 0, 255),0.2);
line(img, pt3, pt4, Scalar(0, 255, 0),0.2);
line(img, pt5, pt6, Scalar(0, 255, 0),0.2);
putText(img, "Left", cvPoint(50,240), FONT_HERSHEY_SIMPLEX, 1, cvScalar(255,0,0), 2, CV_AA);
putText(img, "Center", cvPoint(280,240), FONT_HERSHEY_SIMPLEX, 1, cvScalar(0,0,255), 2, CV_AA);
putText(img, "Right", cvPoint(480,240), FONT_HERSHEY_SIMPLEX, 1, cvScalar(255,0,0), 2, CV_AA);
if (display_tracking_image == 1){
imshow( "Face tracker", img );
}
}
};
int main(int argc, char** argv)
{
ros::init(argc, argv, "Face tracker");
Face_Detector ic;
ros::spin();
return 0;
}
