摄像头与激光雷达微波雷达的融合算法之二标定

人工智能 xiaorun 1520次浏览 0个评论

前言   前段时间说到小编手里有两个传感器,6个激光雷达与摄像头,还有一个微波摄像头,分别装在一个路口的不同地方,需要将这些传感器进行融合输出目标列表。但是要做到融合首先第一步就是标定,做空间同步,第二是时间同步。   接下来我以激光雷达与摄像头为例,其中激光雷达首先需要做目标检测,多目标追踪输出的为目标结构化数据(此知识算法不在此处延申,大家可查查激光雷达处理的相关算法文章)   群号交流:193369905   1、联合标定原理   在用OpenCV中的函数,通过4对对应的点的坐标计算两个图像之间单应矩阵H,然后调用射影变换函数,将一幅图像变换到另一幅图像的视角中。当时只是知道通过单应矩阵,能够将图像1中的像素坐标(u1,v1))变换到图像2中对应的位置上(u2,v2),而没有深究其中的变换关系。   单应(Homography)是射影几何中的概念,又称为射影变换。它把一个射影平面上的点(三维齐次矢量)映射到另一个射影平面上,并且把直线映射为直线,具有保线性质。总的来说,单应是关于三维齐次矢量的一种线性变换,可以用一个3×3的非奇异矩阵H表示这是一个齐次坐标的等式,

     x1=Hx2

  在这里H是一个3×3的齐次矩阵,具有8个未知量。假设已经取得了两图像之间的单应,则可单应矩阵H可以将两幅图像关联起来。这有了很多实际的应用,例如图像的校正、对齐以及在SLAM中估计两个相机间的运动。此处我用作做为联合标定。   首先我们将是雷达平面假设为一个二维水平面,忽略其坡度。   即可得 雷达平面上点p1(x1,y1),与图像上点p2(x2,y2)是一对匹配得点对,其单应性矩阵为H,则有
摄像头与激光雷达微波雷达的融合算法之二标定   接下来我们求解这个矩阵   在真实的应用场景中,我们计算的点对中都会包含噪声。比如点的位置偏差几个像素,甚至出现特征点对误匹配的现象,如果只使用4个点对来计算单应矩阵,那会出现很大的误差。因此,为了使得计算更精确,一般都会使用远大于4个点对来计算单应矩阵。另外上述方程组采用直接线性解法通常很难得到最优解,所以实际使用中一般会用其他优化方法,如奇异值分解、Levenberg-Marquarat(LM)算法等进行求解。   本工程里使用了四种方法,分别为直接解方程组,最小二乘法,ransac方法,基于PROSAC的鲁棒算法,具体解法可自行百度。   2、标定效果   在这里由于是路口,不同于自动驾驶车,我们可以在感兴趣融合区域联合标定十个点,同时得到两个传感器得目标结果值   如下所示:
摄像头与激光雷达微波雷达的融合算法之二标定   接下来解出点对的单应性矩阵即可,在这里我写了一个类,调用类方法即可得,其中h为雷达坐标到图像坐标变换值,h_inv为图像到3d世界雷达坐标。
摄像头与激光雷达微波雷达的融合算法之二标定   3、标定效果验证   最后我们把标定结果,根据雷达目标计算出图像坐标如图所示
摄像头与激光雷达微波雷达的融合算法之二标定   我们可以看到目标点基本重合。   最后我放出部分相关核心代码:

#include "CamCal.h"
#include<string>
#include<stdio.h>
C2dPtSel o2dPtSel;

void on_mouse(int event, int x, int y, int flags, void*)  // mouse event
{
	if (!o2dPtSel.chkImgLd())
	{
		std::cout << "Error: on_mouse(): frame image is unloaded" << std::endl;
		return;
	}

	if (event == CV_EVENT_FLAG_LBUTTON)
		o2dPtSel.addNd(x, y);

	return;
}

CCamCal::CCamCal(void)
{
	// list of 3D points for PnP
	std::vector<cv::Point2f>().swap(m_vo3dPt);

	// list of 2D points for PnP
	std::vector<cv::Point2f>().swap(m_vo2dPt);
}

CCamCal::~CCamCal(void)
{
	// list of 3D points for PnP
	std::vector<cv::Point2f>().swap(m_vo3dPt);

	// list of 2D points for PnP
	std::vector<cv::Point2f>().swap(m_vo2dPt);
}

void CCamCal::initialize(CCfg oCfg, cv::Mat oImgFrm)
{
	// configuration parameters
	m_oCfg = oCfg;

	// frame image
	m_oImgFrm = oImgFrm.clone();

	// list of 3D points for PnP
	m_vo3dPt = m_oCfg.getCal3dPtLs();

	// list of 2D points for PnP
	if (!m_oCfg.getCalSel2dPtFlg())
		m_vo2dPt = m_oCfg.getCal2dPtLs();

	// homography matrix
	m_oHomoMat = cv::Mat(3, 3, CV_64F);

	// reprojection error
	m_fReprojErr = DBL_MAX;
}

void CCamCal::process(void)
{
	// select 2D points if they are not provided in the configuration file
	if (m_oCfg.getCalSel2dPtFlg())
	{
		std::vector<cv::Point2f>().swap(m_vo2dPt);
		o2dPtSel.initialize(m_oCfg, m_oImgFrm);
		std::vector<cv::Point> vo2dPt = o2dPtSel.process();
		std::cout << "Selected 2D points on the frame image: " << std::endl;
		for (int i = 0; i < vo2dPt.size(); i++)
		{
			m_vo2dPt.push_back(vo2dPt[i]);
			if ((vo2dPt.size() - 1) > i)
				std::cout << "[ " << vo2dPt[i].x << ", " << vo2dPt[i].y << " ]," << std::endl;
			else
				std::cout << "[ " << vo2dPt[i].x << ", " << vo2dPt[i].y << " ]" << std::endl;
		}
	}
	m_fprojErr=calcprojErr(m_oHomoMat, m_oCfg.getCalTyp(), m_oCfg.getCalRansacReprojThld());

	// compute homography matrix
	if (-1 == m_oCfg.getCalTyp())
		// run all calibration types
        	runAllCalTyp();
	else
	{
        	m_oHomoMat = cv::findHomography(m_vo3dPt, m_vo2dPt, m_oCfg.getCalTyp(), m_oCfg.getCalRansacReprojThld());
        	m_fReprojErr = calcReprojErr(m_oHomoMat, m_oCfg.getCalTyp(), m_oCfg.getCalRansacReprojThld());
	}

	std::cout << std::endl;
}

void CCamCal::output(void)
{
	// output text file of homography matrix
	outTxt();

	// plot a display grid on the ground plane
	pltDispGrd();
}

void CCamCal::runAllCalTyp(void)
{
	cv::Mat oHomoMat;
	double fReprojErr;

	// a regular method using all the points
	try
	{
		oHomoMat = cv::findHomography(m_vo3dPt, m_vo2dPt, 0, 0);
		fReprojErr = calcReprojErr(oHomoMat, 0, 0);
		if (fReprojErr < m_fReprojErr)
		{
        		m_fReprojErr = fReprojErr;
        		m_oHomoMat = oHomoMat;
		}
        }
        catch(cv::Exception& e)
        {
                const char* pcErrMsg = e.what();
                std::cout << "Exception caught: " << pcErrMsg << std::endl;
        }

	// Least-Median robust method
	try
	{
		oHomoMat = cv::findHomography(m_vo3dPt, m_vo2dPt, 4, 0);
		fReprojErr = calcReprojErr(oHomoMat, 4, 0);
		if (fReprojErr < m_fReprojErr)
		{
        		m_fReprojErr = fReprojErr;
        		m_oHomoMat = oHomoMat;
		}
        }
        catch(cv::Exception& e)
        {
                const char* pcErrMsg = e.what();
                std::cout << "Exception caught: " << pcErrMsg << std::endl;
        }

	// RANSAC-based robust method
	for (double t = 100; t >= 10; t -= 5)
	{
		try
		{
			oHomoMat = cv::findHomography(m_vo3dPt, m_vo2dPt, 8, t);
			fReprojErr = calcReprojErr(oHomoMat, 8, t);
			if (fReprojErr < m_fReprojErr)
        		{
        			m_fReprojErr = fReprojErr;
        			m_oHomoMat = oHomoMat;
        		}
        	}
        	catch(cv::Exception& e)
        	{
                	const char* pcErrMsg = e.what();
                	std::cout << "Exception caught: " << pcErrMsg << std::endl;
        	}
	}
}

double CCamCal::calcReprojErr(cv::Mat oHomoMat, int nCalTyp, double fCalRansacReprojThld)
{
	double fReprojErr = 0;

	for (int i = 0; i < m_vo3dPt.size(); i++)
	{
		cv::Mat o3dPtMat(3, 1, CV_64F);
		cv::Mat o2dPtMat(3, 1, CV_64F);
		cv::Point2f o2dPt;

		o3dPtMat.at<double>(0, 0) = m_vo3dPt[i].x;
		o3dPtMat.at<double>(1, 0) = m_vo3dPt[i].y;
		o3dPtMat.at<double>(2, 0) = 1;
		o2dPtMat = oHomoMat * o3dPtMat;
		o2dPt = cv::Point2f((o2dPtMat.at<double>(0, 0) / o2dPtMat.at<double>(2, 0)), (o2dPtMat.at<double>(1, 0) / o2dPtMat.at<double>(2, 0)));

		fReprojErr += cv::norm(m_vo2dPt[i] - o2dPt);

	}

	fReprojErr /= m_vo3dPt.size();

	if (8 == nCalTyp)
		std::cout << "Average reprojection error of method #" << nCalTyp << " (threshold: " << fCalRansacReprojThld << "): " << fReprojErr << std::endl;
	else
		std::cout << "Average reprojection error of method #" << nCalTyp << ": " << fReprojErr << std::endl;

    return fReprojErr;
}


double CCamCal::calcprojErr(cv::Mat oHomoMat, int nCalTyp, double fCalRansacReprojThld)
{
	double fReprojErr = 0;
	double s=0;
	cv::Mat oHomoMat_inv= cv::findHomography(m_vo2dPt, m_vo3dPt, 0, 0);
	for (int i = 0; i < m_vo3dPt.size(); i++)
	{
		cv::Mat o3dPtMat(3, 1, CV_64F);
		cv::Mat o2dPtMat(3, 1, CV_64F);
		cv::Point2f o3dPt;

		o2dPtMat.at<double>(0, 0) = m_vo2dPt[i].x;
		o2dPtMat.at<double>(1, 0) = m_vo2dPt[i].y;
		o2dPtMat.at<double>(2, 0) = 1;
		o3dPtMat = oHomoMat_inv * o2dPtMat;
		o3dPt = cv::Point2f((o3dPtMat.at<double>(0, 0) / o3dPtMat.at<double>(2, 0)), (o3dPtMat.at<double>(1, 0) / o3dPtMat.at<double>(2, 0)));
		std::cout<<"point2d["<< m_vo2dPt[i].x<<" "<<m_vo2dPt[i].y<<"]"<<" world cordinate is: "<<o3dPt<<std::endl;
		fReprojErr += cv::norm(m_vo3dPt[i] - o3dPt);

	}

	fReprojErr /= m_vo3dPt.size();

	if (8 == nCalTyp)
		std::cout << "Average reprojection error of method #" << nCalTyp << " (threshold: " << fCalRansacReprojThld << "): " << fReprojErr << std::endl;
	else
		std::cout << "Average reprojection error of method #" << nCalTyp << ": " << fReprojErr << std::endl;

    return fReprojErr;
}


void CCamCal::outTxt(void)
{
	FILE* pfHomoMat = fopen(m_oCfg.getOutCamMatPth(), "w");

	fprintf(pfHomoMat, "Homography matrix: %.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf\n",
		m_oHomoMat.at<double>(0, 0), m_oHomoMat.at<double>(0, 1), m_oHomoMat.at<double>(0, 2),
		m_oHomoMat.at<double>(1, 0), m_oHomoMat.at<double>(1, 1), m_oHomoMat.at<double>(1, 2),
		m_oHomoMat.at<double>(2, 0), m_oHomoMat.at<double>(2, 1), m_oHomoMat.at<double>(2, 2));
	printf("Homography matrix: %.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf\n",
		m_oHomoMat.at<double>(0, 0), m_oHomoMat.at<double>(0, 1), m_oHomoMat.at<double>(0, 2),
		m_oHomoMat.at<double>(1, 0), m_oHomoMat.at<double>(1, 1), m_oHomoMat.at<double>(1, 2),
		m_oHomoMat.at<double>(2, 0), m_oHomoMat.at<double>(2, 1), m_oHomoMat.at<double>(2, 2));

	if (m_oCfg.getCalDistFlg())
	{
	    cv::Mat oCalIntMat = m_oCfg.getCalIntMat();
	    fprintf(pfHomoMat, "Intrinsic parameter matrix: %.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf\n",
            	oCalIntMat.at<double>(0, 0), oCalIntMat.at<double>(0, 1), oCalIntMat.at<double>(0, 2),
            	oCalIntMat.at<double>(1, 0), oCalIntMat.at<double>(1, 1), oCalIntMat.at<double>(1, 2),
            	oCalIntMat.at<double>(2, 0), oCalIntMat.at<double>(2, 1), oCalIntMat.at<double>(2, 2));
	    printf("Intrinsic parameter matrix: %.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf;%.15lf %.15lf %.15lf\n",
            	oCalIntMat.at<double>(0, 0), oCalIntMat.at<double>(0, 1), oCalIntMat.at<double>(0, 2),
            	oCalIntMat.at<double>(1, 0), oCalIntMat.at<double>(1, 1), oCalIntMat.at<double>(1, 2),
            	oCalIntMat.at<double>(2, 0), oCalIntMat.at<double>(2, 1), oCalIntMat.at<double>(2, 2));

		cv::Mat oCalDistCoeffMat = m_oCfg.getCalDistCoeffMat();
		fprintf(pfHomoMat, "Distortion coefficients: %.15lf %.15lf %.15lf %.15lf\n",
			oCalDistCoeffMat.at<double>(0), oCalDistCoeffMat.at<double>(1),
			oCalDistCoeffMat.at<double>(2), oCalDistCoeffMat.at<double>(3));
		printf("Distortion coefficients: %.15lf %.15lf %.15lf %.15lf\n",
			oCalDistCoeffMat.at<double>(0), oCalDistCoeffMat.at<double>(1),
			oCalDistCoeffMat.at<double>(2), oCalDistCoeffMat.at<double>(3));
	}

	fprintf(pfHomoMat, "Reprojection error: %.15lf\n", m_fReprojErr);
	printf("Reprojection error: %.15lf\n", m_fReprojErr);

	fclose(pfHomoMat);
}

void CCamCal::pltDispGrd(void)
{
	cv::Mat oImgPlt = m_oImgFrm.clone();
	cv::Size oDispGrdDim = m_oCfg.getCalDispGrdDim();

	// find the limits of the 3D grid on the ground plane
	double fXMin = DBL_MAX;
	double fYMin = DBL_MAX;
	double fXMax = -DBL_MAX;
	double fYMax = -DBL_MAX;

	for (int i = 0; i < m_vo3dPt.size(); i++)
	{
		if (fXMin > m_vo3dPt[i].x)
			fXMin = m_vo3dPt[i].x;

		if (fYMin > m_vo3dPt[i].y)
			fYMin = m_vo3dPt[i].y;

		if (fXMax < m_vo3dPt[i].x)
			fXMax = m_vo3dPt[i].x;

		if (fYMax < m_vo3dPt[i].y)
			fYMax = m_vo3dPt[i].y;
	}

	// compute the endpoints for the 3D grid on the ground plane
	std::vector<cv::Point2f> vo3dGrdPtTop, vo3dGrdPtBtm, vo3dGrdPtLft, vo3dGrdPtRgt;

	for (int x = 0; x < oDispGrdDim.width; x++)
	{
		vo3dGrdPtTop.push_back(cv::Point2f((fXMin + (x * ((fXMax - fXMin) / (oDispGrdDim.width - 1)))), fYMin));
		vo3dGrdPtBtm.push_back(cv::Point2f((fXMin + (x * ((fXMax - fXMin) / (oDispGrdDim.width - 1)))), fYMax));
	}

	for (int y = 0; y < oDispGrdDim.height; y++)
	{
		vo3dGrdPtLft.push_back(cv::Point2f(fXMin, (fYMin + (y * ((fYMax - fYMin) / (oDispGrdDim.height - 1))))));
		vo3dGrdPtRgt.push_back(cv::Point2f(fXMax, (fYMin + (y * ((fYMax - fYMin) / (oDispGrdDim.height - 1))))));
	}

	// compute the endpoints for the projected 2D grid
	std::vector<cv::Point2f> vo2dGrdPtTop, vo2dGrdPtBtm, vo2dGrdPtLft, vo2dGrdPtRgt;

	for (int i = 0; i < oDispGrdDim.width; i++)
	{
		cv::Mat o3dPtMat(3, 1, CV_64F);
		cv::Mat o2dPtMat(3, 1, CV_64F);

		o3dPtMat.at<double>(0, 0) = vo3dGrdPtTop[i].x;
		o3dPtMat.at<double>(1, 0) = vo3dGrdPtTop[i].y;
		o3dPtMat.at<double>(2, 0) = 1;
		o2dPtMat = m_oHomoMat * o3dPtMat;
		vo2dGrdPtTop.push_back(cv::Point2f((o2dPtMat.at<double>(0, 0) / o2dPtMat.at<double>(2, 0)), (o2dPtMat.at<double>(1, 0) / o2dPtMat.at<double>(2, 0))));

		o3dPtMat.at<double>(0, 0) = vo3dGrdPtBtm[i].x;
		o3dPtMat.at<double>(1, 0) = vo3dGrdPtBtm[i].y;
		o3dPtMat.at<double>(2, 0) = 1;
		o2dPtMat = m_oHomoMat * o3dPtMat;
		vo2dGrdPtBtm.push_back(cv::Point2f((o2dPtMat.at<double>(0, 0) / o2dPtMat.at<double>(2, 0)), (o2dPtMat.at<double>(1, 0) / o2dPtMat.at<double>(2, 0))));
	}

	for (int i = 0; i < oDispGrdDim.height; i++)
	{
		cv::Mat o3dPtMat(3, 1, CV_64F);
		cv::Mat o2dPtMat(3, 1, CV_64F);

		o3dPtMat.at<double>(0, 0) = vo3dGrdPtLft[i].x;
		o3dPtMat.at<double>(1, 0) = vo3dGrdPtLft[i].y;
		o3dPtMat.at<double>(2, 0) = 1;
		o2dPtMat = m_oHomoMat * o3dPtMat;
		vo2dGrdPtLft.push_back(cv::Point2f((o2dPtMat.at<double>(0, 0) / o2dPtMat.at<double>(2, 0)), (o2dPtMat.at<double>(1, 0) / o2dPtMat.at<double>(2, 0))));

		o3dPtMat.at<double>(0, 0) = vo3dGrdPtRgt[i].x;
		o3dPtMat.at<double>(1, 0) = vo3dGrdPtRgt[i].y;
		o3dPtMat.at<double>(2, 0) = 1;
		o2dPtMat = m_oHomoMat * o3dPtMat;
		vo2dGrdPtRgt.push_back(cv::Point2f((o2dPtMat.at<double>(0, 0) / o2dPtMat.at<double>(2, 0)), (o2dPtMat.at<double>(1, 0) / o2dPtMat.at<double>(2, 0))));
	}

	// draw grid lines on the frame image
	for (int i = 0; i < oDispGrdDim.width; i++)
		cv::line(oImgPlt, vo2dGrdPtTop[i], vo2dGrdPtBtm[i], cv::Scalar(int(255.0 * ((double)i / (double)oDispGrdDim.width)), 127, 127), 2, CV_AA);

	for (int i = 0; i < oDispGrdDim.width; i++)
		cv::line(oImgPlt, vo2dGrdPtLft[i], vo2dGrdPtRgt[i], cv::Scalar(127, 127, int(255.0 * ((double)i / (double)oDispGrdDim.width))), 2, CV_AA);

	// plot the 2D points
	for (int i = 0; i < m_vo2dPt.size(); i++)
	{
		char acPtIdx[32];
		cv::circle(oImgPlt, m_vo2dPt[i], 6, cv::Scalar(255, 0, 0), 1, CV_AA);  // draw the circle
		sprintf(acPtIdx, "%d", i);
		cv::putText(oImgPlt, acPtIdx, m_vo2dPt[i], cv::FONT_HERSHEY_SIMPLEX, 1, cv::Scalar(255,0, 255), 2);
	}

	// plot the projected 2D points
		// plot the 2D points
	for (int i = 0; i < m_vo2dPt.size(); i++)
	{
		cv::Mat o3dPtMat(3, 1, CV_64F);
		cv::Mat o2dPtMat(3, 1, CV_64F);

		o3dPtMat.at<double>(0, 0) = m_vo3dPt[i].x;
		o3dPtMat.at<double>(1, 0) = m_vo3dPt[i].y;
		o3dPtMat.at<double>(2, 0) = 1;
		o2dPtMat = m_oHomoMat * o3dPtMat;

		cv::circle(oImgPlt, cv::Point2f((o2dPtMat.at<double>(0, 0) / o2dPtMat.at<double>(2, 0)), (o2dPtMat.at<double>(1, 0) / o2dPtMat.at<double>(2, 0))),
			12, cv::Scalar(0, 0, 255), 1, CV_AA);  // draw the circle
	}

	// display plotted image
	cv::namedWindow("3D grid on the ground plane", CV_WINDOW_NORMAL);
	cv::imshow("3D grid on the ground plane", oImgPlt);
	cv::waitKey(0);
	cv::destroyAllWindows();

	// save plotted image
	if (m_oCfg.getOutCalDispFlg())
		cv::imwrite(m_oCfg.getOutCalDispPth(), oImgPlt);
}


C2dPtSel::C2dPtSel(void)
{

}

C2dPtSel::~C2dPtSel(void)
{

}

void C2dPtSel::initialize(CCfg oCfg, cv::Mat oImgFrm)
{
	// configuration parameters
	m_oCfg = oCfg;

	// frame image for plotting results
	m_oImgFrm = oImgFrm.clone();
}

std::vector<cv::Point> C2dPtSel::process(void)
{
	std::vector<cv::Point> voVanPt;

	if (m_oCfg.getCalSel2dPtFlg())
	{
		std::cout << "Hot keys: \n"
			<< "\tESC - exit\n"
			<< "\tr - re-select a set of 2D points\n"
			<< "\to - finish selecting a set of 2D points\n"
			<< std::endl;

		cv::Mat oImgFrm = m_oImgFrm.clone();

		cv::namedWindow("selector of 2D points", CV_WINDOW_NORMAL);
		cv::imshow("selector of 2D points", m_oImgFrm);
		cv::setMouseCallback("selector of 2D points", on_mouse);  // register for mouse event

		while (1)
		{
			int nKey = cv::waitKey(0);	// read keyboard event

			if (nKey == 27)
				break;

			if (nKey == 'r')  // reset the nodes
			{
				std::vector<cv::Point>().swap(m_voNd);
				m_oImgFrm = oImgFrm.clone();
				cv::imshow("selector of 2D points", m_oImgFrm);
                                cv::waitKey(0);
			}

			if (nKey == 'o')	// finish selection of pairs of test points
			{
				cv::destroyWindow("selector of 2D points");
				std::vector<cv::Point2f> vo3dPt = m_oCfg.getCal3dPtLs();
				if (vo3dPt.size() == m_voNd.size())
					return m_voNd;
				else
				{
					std::cout << "Error: Mis-match between the number of selected 2D points and the number of 3D points." << std::endl;
					break;
				}
			}
		}
	}
}

void C2dPtSel::addNd(int nX, int nY)
{
	char acNdIdx[32];
	cv::Point oCurrNd;
	oCurrNd.x = nX;
	oCurrNd.y = nY;

	m_voNd.push_back(oCurrNd);
	// std::cout << "current node(" << oCurrNd.x << "," << oCurrNd.y << ")" << std::endl;	// for debug
	cv::circle(m_oImgFrm, oCurrNd, 6, cv::Scalar(255, 0, 0), 1, CV_AA);  // draw the circle
	sprintf(acNdIdx, "%d", (int)(m_voNd.size() - 1));
	cv::putText(m_oImgFrm, acNdIdx, oCurrNd, cv::FONT_HERSHEY_SIMPLEX, 1, cv::Scalar(0, 0, 255), 2);
	cv::imshow("selector of 2D points", m_oImgFrm);
}

  最后总结 好多朋友问我怎么将多个激光雷达与多个摄像头融合,在这里我简单解答下,摄像头与激光雷达首先各自均要做内部融合,例如6个激光雷达首先要进行内部标定拼接,这里我放张图吧。
摄像头与激光雷达微波雷达的融合算法之二标定   标红处为激光雷达安装位置,拼接完输出结构化数据再与摄像头进行融合。   后续接下来会讲如何进行目标级别融合。。。。。。有兴趣童鞋可加群193369905交流,也可提交相关简历,加入我们或者实习。。。


开心洋葱 , 版权所有丨如未注明 , 均为原创丨未经授权请勿修改 , 转载请注明摄像头与激光雷达微波雷达的融合算法之二标定
喜欢 (0)

您必须 登录 才能发表评论!

加载中……
