python code for solving eigenvalue problem by Jacobi’s method
''' lam,x = jacobi(a,tol = 1.0e-9). Solution of std. eigenvalue problem [a]{x} = lam{x} by Jacobi's method. Returns eigenvalues in vector {lam} and the eigenvectors as columns of matrix [x]. ''' from numpy import array,identity,diagonal from math import sqrt def jacobi(a,tol = 1.0e-9): # Jacobi method def maxElem(a): # Find largest off-diag. element a[k,l] n = len(a) aMax = 0.0 for i in range(n-1): for j in range(i+1,n): if abs(a[i,j]) >= aMax: aMax = abs(a[i,j]) k = i; l = j return aMax,k,l def rotate(a,p,k,l): # Rotate to make a[k,l] = 0 n = len(a) aDiff = a[l,l] - a[k,k] if abs(a[k,l]) < abs(aDiff)*1.0e-36: t = a[k,l]/aDiff else: phi = aDiff/(2.0*a[k,l]) t = 1.0/(abs(phi) + sqrt(phi**2 + 1.0)) if phi < 0.0: t = -t c = 1.0/sqrt(t**2 + 1.0); s = t*c tau = s/(1.0 + c) temp = a[k,l] a[k,l] = 0.0 a[k,k] = a[k,k] - t*temp a[l,l] = a[l,l] + t*temp for i in range(k): # Case of i < k temp = a[i,k] a[i,k] = temp - s*(a[i,l] + tau*temp) a[i,l] = a[i,l] + s*(temp - tau*a[i,l]) for i in range(k+1,l): # Case of k < i < l temp = a[k,i] a[k,i] = temp - s*(a[i,l] + tau*a[k,i]) a[i,l] = a[i,l] + s*(temp - tau*a[i,l]) for i in range(l+1,n): # Case of i > l temp = a[k,i] a[k,i] = temp - s*(a[l,i] + tau*temp) a[l,i] = a[l,i] + s*(temp - tau*a[l,i]) for i in range(n): # Update transformation matrix temp = p[i,k] p[i,k] = temp - s*(p[i,l] + tau*p[i,k]) p[i,l] = p[i,l] + s*(temp - tau*p[i,l]) n = len(a) maxRot = 5*(n**2) # Set limit on number of rotations p = identity(n)*1.0 # Initialize transformation matrix for i in range(maxRot): # Jacobi rotation loop aMax,k,l = maxElem(a) if aMax < tol: return diagonal(a),p rotate(a,p,k,l) print 'Jacobi method did not converge'
