前言
众所周知，Catalyst Optimizer是Spark SQL的核心，它主要负责将SQL语句转换成最终的物理执行计划，在一定程度上决定了SQL执行的性能。
Catalyst在由Optimized Logical Plan生成Physical Plan的过程中，会根据：
abstract class SparkStrategies extends QueryPlanner[SparkPlan]
中的JoinSelection通过一些规则按照顺序进行模式匹配，从而确定join的最终执行策略，并且策略的选择会按照执行效率由高到低的优先级排列。
在了解join策略选择之前，首先看几个先决条件：
1. build table的选择
Hash Join的第一步就是根据两表之中较小的那一个构建哈希表，这个小表就叫做build table，大表则称为probe table，因为需要拿小表形成的哈希表来”探测”它。源码如下：
/* 左表作为build table的条件，join类型需满足：
1. InnerLike：实现目前包括inner join和cross join
2. RightOuter：right outer join
*/
private def canBuildLeft(joinType: JoinType): Boolean = joinType match {
case _: InnerLike | RightOuter => true
case _ => false
}
/* 右表作为build table的条件，join类型需满足（第1种是在业务开发中写的SQL主要适配的）：
1. InnerLike、LeftOuter（left outer join）、LeftSemi（left semi join）、LeftAnti（left anti join）
2. ExistenceJoin：only used in the end of optimizer and physical plans, we will not generate SQL for this join type
*/
private def canBuildRight(joinType: JoinType): Boolean = joinType match {
case _: InnerLike | LeftOuter | LeftSemi | LeftAnti | _: ExistenceJoin => true
case _ => false
}
2. 满足什么条件的表才能被广播
如果一个表的大小小于或等于参数spark.sql.autoBroadcastJoinThreshold（默认10M）配置的值，那么就可以广播该表。源码如下：
private def canBroadcastBySizes(joinType: JoinType, left: LogicalPlan, right: LogicalPlan)
: Boolean = {
val buildLeft = canBuildLeft(joinType) && canBroadcast(left)
val buildRight = canBuildRight(joinType) && canBroadcast(right)
buildLeft || buildRight
}
private def canBroadcast(plan: LogicalPlan): Boolean = {
plan.stats.sizeInBytes >= 0 && plan.stats.sizeInBytes <= conf.autoBroadcastJoinThreshold
}
private def broadcastSideBySizes(joinType: JoinType, left: LogicalPlan, right: LogicalPlan)
: BuildSide = {
val buildLeft = canBuildLeft(joinType) && canBroadcast(left)
val buildRight = canBuildRight(joinType) && canBroadcast(right)
// 最终会调用broadcastSide
broadcastSide(buildLeft, buildRight, left, right)
}
除了通过上述表的大小满足一定条件之外，我们也可以通过直接在Spark SQL中显示使用hint方式（/*+ BROADCAST(small_table) */），直接指定要广播的表，源码如下：
private def canBroadcastByHints(joinType: JoinType, left: LogicalPlan, right: LogicalPlan)
: Boolean = {
val buildLeft = canBuildLeft(joinType) && left.stats.hints.broadcast
val buildRight = canBuildRight(joinType) && right.stats.hints.broadcast
buildLeft || buildRight
}
private def broadcastSideByHints(joinType: JoinType, left: LogicalPlan, right: LogicalPlan)
: BuildSide = {
val buildLeft = canBuildLeft(joinType) && left.stats.hints.broadcast
val buildRight = canBuildRight(joinType) && right.stats.hints.broadcast
// 最终会调用broadcastSide
broadcastSide(buildLeft, buildRight, left, right)
}
无论是通过表大小进行广播还是根据是否指定hint进行表广播，最终都会调用broadcastSide，来决定应该广播哪个表：
private def broadcastSide(
canBuildLeft: Boolean,
canBuildRight: Boolean,
left: LogicalPlan,
right: LogicalPlan): BuildSide = {
def smallerSide =
if (right.stats.sizeInBytes <= left.stats.sizeInBytes) BuildRight else BuildLeft
if (canBuildRight && canBuildLeft) {
// 如果左表和右表都能作为build table，则将根据表的统计信息，确定physical size较小的表作为build table（即使两个表都被指定了hint）
smallerSide
} else if (canBuildRight) {
// 上述条件不满足，优先判断右表是否满足build条件，满足则广播右表。否则，接着判断左表是否满足build条件
BuildRight
} else if (canBuildLeft) {
BuildLeft
} else {
// 如果左表和右表都不能作为build table，则将根据表的统计信息，确定physical size较小的表作为build table。目前主要用于broadcast nested loop join
smallerSide
}
}
从上述源码可知，即使用户指定了广播hint，实际执行时，不一定按照hint的表进行广播。
3. 是否可构造本地HashMap
应用于Shuffle Hash Join中，源码如下：
// 逻辑计划的单个分区足够小到构建一个hash表
// 注意：要求分区数是固定的。如果分区数是动态的，还需满足其他条件
private def canBuildLocalHashMap(plan: LogicalPlan): Boolean = {
// 逻辑计划的physical size小于spark.sql.autoBroadcastJoinThreshold * spark.sql.shuffle.partitions（默认200）时，即可构造本地HashMap
plan.stats.sizeInBytes < conf.autoBroadcastJoinThreshold * conf.numShufflePartitions
}
我们知道，SparkSQL目前主要实现了3种join：Broadcast Hash Join、ShuffledHashJoin、Sort Merge Join。那么Catalyst在处理SQL语句时，是依据什么规则进行join策略选择的呢？
1. Broadcast Hash Join
主要根据hint和size进行判断是否满足条件。
// broadcast hints were specified
case ExtractEquiJoinKeys(joinType, leftKeys, rightKeys, condition, left, right)
if canBroadcastByHints(joinType, left, right) =>
val buildSide = broadcastSideByHints(joinType, left, right)
Seq(joins.BroadcastHashJoinExec(
leftKeys, rightKeys, joinType, buildSide, condition, planLater(left), planLater(right)))
// broadcast hints were not specified, so need to infer it from size and configuration.
case ExtractEquiJoinKeys(joinType, leftKeys, rightKeys, condition, left, right)
if canBroadcastBySizes(joinType, left, right) =>
val buildSide = broadcastSideBySizes(joinType, left, right)
Seq(joins.BroadcastHashJoinExec(
leftKeys, rightKeys, joinType, buildSide, condition, planLater(left), planLater(right)))
2. Shuffle Hash Join
选择Shuffle Hash Join需要同时满足以下条件：
-
spark.sql.join.preferSortMergeJoin为false，即Shuffle Hash Join优先于Sort Merge Join
-
右表或左表是否能够作为build table
-
是否能构建本地HashMap
-
以右表为例，它的逻辑计划大小要远小于左表大小（默认3倍）
上述条件优先检查右表。
case ExtractEquiJoinKeys(joinType, leftKeys, rightKeys, condition, left, right)
if !conf.preferSortMergeJoin && canBuildRight(joinType) && canBuildLocalHashMap(right)
&& muchSmaller(right, left) ||
!RowOrdering.isOrderable(leftKeys) =>
Seq(joins.ShuffledHashJoinExec(
leftKeys, rightKeys, joinType, BuildRight, condition, planLater(left), planLater(right)))
case ExtractEquiJoinKeys(joinType, leftKeys, rightKeys, condition, left, right)
if !conf.preferSortMergeJoin && canBuildLeft(joinType) && uildLocalHashMap(left)
&& muchSmaller(left, right) ||
!RowOrdering.isOrderable(leftKeys) =>
Seq(joins.ShuffledHashJoinExec(
leftKeys, rightKeys, joinType, BuildLeft, condition, planLater(left), planLater(right)))
private def muchSmaller(a: LogicalPlan, b: LogicalPlan): Boolean = {
a.stats.sizeInBytes * 3 <= b.stats.sizeInBytes
}
如果不满足上述条件，但是如果参与join的表的key无法被排序，即无法使用Sort Merge Join，最终也会选择Shuffle Hash Join。
!RowOrdering.isOrderable(leftKeys) def isOrderable(exprs: Seq[Expression]): Boolean = exprs.forall(e => isOrderable(e.dataType))
3. Sort Merge Join
如果上面两种join策略（Broadcast Hash Join和Shuffle Hash Join）都不符合条件，并且参与join的key是可排序的，就会选择Sort Merge Join。
case ExtractEquiJoinKeys(joinType, leftKeys, rightKeys, condition, left, right)
if RowOrdering.isOrderable(leftKeys) =>
joins.SortMergeJoinExec(
leftKeys, rightKeys, joinType, condition, planLater(left), planLater(right)) :: Nil
4. Without joining keys
Broadcast Hash Join、Shuffle Hash Join和Sort Merge Join都属于经典的ExtractEquiJoinKeys（等值连接条件）。
对于非ExtractEquiJoinKeys，则会优先检查表是否可以被广播（hint或者size）。如果可以，则会使用BroadcastNestedLoopJoin（简称BNLJ），熟悉Nested Loop Join则不难理解BNLJ，主要却别在于BNLJ加上了广播表。
源码如下：
// Pick BroadcastNestedLoopJoin if one side could be broadcast
case j @ logical.Join(left, right, joinType, condition)
if canBroadcastByHints(joinType, left, right) =>
val buildSide = broadcastSideByHints(joinType, left, right)
joins.BroadcastNestedLoopJoinExec(
planLater(left), planLater(right), buildSide, joinType, condition) :: Nil
case j @ logical.Join(left, right, joinType, condition)
if canBroadcastBySizes(joinType, left, right) =>
val buildSide = broadcastSideBySizes(joinType, left, right)
joins.BroadcastNestedLoopJoinExec(
planLater(left), planLater(right), buildSide, joinType, condition) :: Nil
如果表不能被广播，又细分为两种情况：
-
若join类型InnerLike（关于InnerLike上面已有介绍）对量表直接进行笛卡尔积处理若
-
上述情况都不满足，最终方案是选择两个表中physical size较小的表进行广播，join策略仍为BNLJ
源码如下：
// Pick CartesianProduct for InnerJoin
case logical.Join(left, right, _: InnerLike, condition) =>
joins.CartesianProductExec(planLater(left), planLater(right), condition) :: Nil
case logical.Join(left, right, joinType, condition) =>
val buildSide = broadcastSide(
left.stats.hints.broadcast, right.stats.hints.broadcast, left, right)
// This join could be very slow or OOM
joins.BroadcastNestedLoopJoinExec(
planLater(left), planLater(right), buildSide, joinType, condition) :: Nil
很显然，无论SQL语句最终的join策略选择笛卡尔积还是BNLJ，效率都很低，这一点在实际应用中，要尽量避免。
