ROS机械臂控制之跟踪二维码

人工智能 神秘老铁 3045次浏览 0个评论

本文使用的机械臂模型是《MoveIt可视化配置及仿真指南》课程中的机械臂模型,并加入了小修改。



1 构建机械臂的xacro模型

创建一个6机械臂的xacro模型文件,完整gazebo模型如下所示:


ROS机械臂控制之跟踪二维码



首先,定义6个link的形状以及末端夹具的大小:

 <!-- link1 properties -->
    <xacro:property name="link0_radius" value="0.05" />
    <xacro:property name="link0_length" value="0.04" />
    <xacro:property name="link0_mass" value="1" />

    <!-- link1 properties -->
    <xacro:property name="link1_radius" value="0.03" />
    <xacro:property name="link1_length" value="0.10" />
    <xacro:property name="link1_mass" value="1" />

    <!-- link2 properties -->
    <xacro:property name="link2_radius" value="0.03" />
    <xacro:property name="link2_length" value="0.14" />
    <xacro:property name="link2_mass" value="0.8" />

    <!-- link3 properties -->
    <xacro:property name="link3_radius" value="0.03" />
    <xacro:property name="link3_length" value="0.15" />
    <xacro:property name="link3_mass" value="0.8" />

    <!-- link4 properties -->
    <xacro:property name="link4_radius" value="0.025" />
    <xacro:property name="link4_length" value="0.06" />
    <xacro:property name="link4_mass" value="0.7" />

    <!-- link5 properties -->
    <xacro:property name="link5_radius" value="0.03" />
    <xacro:property name="link5_length" value="0.06" />
    <xacro:property name="link5_mass" value="0.7" />

    <!-- link6 properties -->
    <xacro:property name="link6_radius" value="0.04" />
    <xacro:property name="link6_length" value="0.02" />
    <xacro:property name="link6_mass" value="0.6" />

    <!-- gripper -->
    <xacro:property name="gripper_length" value="0.03" />
    <xacro:property name="gripper_width" value="0.01" />
    <xacro:property name="gripper_height" value="0.06" />
    <xacro:property name="gripper_mass" value="0.5" />



接着,需要设置每一个Link的详细参数以及两个Link连接处的joint的类型和旋转轴:

 <!-- Gripper frame -->
    <xacro:property name="grasp_frame_radius" value="0.001" />

    <!-- Macro for inertia matrix -->
    <xacro:macro name="cylinder_inertial_matrix" params="m r h">
        <inertial>
            <mass value="${m}" />
            <inertia ixx="${m*(3*r*r+h*h)/12}" ixy = "0" ixz = "0"
                iyy="${m*(3*r*r+h*h)/12}" iyz = "0"
                izz="${m*r*r/2}" />
        </inertial>
    </xacro:macro>

    <xacro:macro name="box_inertial_matrix" params="m w h d">
        <inertial>
            <mass value="${m}" />
            <inertia ixx="${m*(h*h+d*d)/12}" ixy = "0" ixz = "0"
                iyy="${m*(w*w+d*d)/12}" iyz = "0"
                izz="${m*(w*w+h*h)/12}" />
        </inertial>
    </xacro:macro>

    <!-- /////////////////////////////////////   ARM BASE    ////////////////////////////////////////////// -->
    <xacro:macro name="arm_base" params="parent xyz rpy">
        <joint name="${parent}_arm_joint" type="fixed">
            <origin xyz="${xyz}" rpy="${rpy}" />
            <parent link="${parent}"/>
            <child link="base_link" />
        </joint>

        <link name="base_link">
            <visual>
                <origin xyz="0 0 0" rpy="0 0 0" />
                <geometry>
                    <box size="0.001 0.001 0.001" />
                </geometry>
            </visual>
        </link>

        <joint name="base_joint" type="fixed">
            <origin xyz="0 0 ${link0_length/2}" rpy="0 0 0" />
            <parent link="base_link"/>
            <child link="link0" />
        </joint>

        <!-- /////////////////////////////////////    LINK0    ////////////////////////////////////////////// -->
        <link name="link0">
            <visual>
                <origin xyz="0 0 0" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link0_radius}" length="${link0_length}"/>
                </geometry>
                <material name="White" />
            </visual>
            <collision>
                <origin xyz="0 0 0" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link0_radius}" length="${link0_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link0_mass}" r="${link0_radius}" h="${link0_length}"/>
        </link>

        <joint name="joint1" type="revolute">
            <parent link="link0"/>
            <child link="link1"/>
            <origin xyz="0 0 ${link0_length/2}" rpy="0 ${M_PI/2} 0" />
            <axis xyz="-1 0 0" />
            <limit effort="300" velocity="1" lower="${-M_PI}" upper="${M_PI}"/>
        </joint>

        <!-- /////////////////////////////////////   LINK1  ////////////////////////////////////////////// -->
        <link name="link1" >
            <visual>
                <origin xyz="-${link1_length/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <cylinder radius="${link1_radius}" length="${link1_length}"/>
                </geometry>
                <material name="Blue" />
            </visual>
            <collision>
                <origin xyz="-${link1_length/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <cylinder radius="${link1_radius}" length="${link1_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link1_mass}" r="${link1_radius}" h="${link1_length}"/>
        </link>

        <joint name="joint2" type="revolute">
            <parent link="link1"/>
            <child link="link2"/>
            <origin xyz="-${link1_length} 0 0.0" rpy="-${M_PI/2} 0 ${M_PI/2}" />
            <axis xyz="1 0 0" />
            <limit effort="300" velocity="1" lower="${-M_PI}" upper="${M_PI}" />
        </joint>

        <!-- ///////////////////////////////////////   LINK2  ////////////////////////////////////////////// -->
        <link name="link2" >
            <visual>
                <origin xyz="0 0 ${link2_length/2}" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link2_radius}" length="${link2_length}"/>
                </geometry>
                <material name="White" />
            </visual>

            <collision>
                <origin xyz="0 0 ${link2_length/2}" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link2_radius}" length="${link2_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link2_mass}" r="${link2_radius}" h="${link2_length}"/>
        </link>

        <joint name="joint3" type="revolute">
            <parent link="link2"/>
            <child link="link3"/>
            <origin xyz="0 0 ${link2_length}" rpy="0 ${M_PI} 0" />
            <axis xyz="-1 0 0" />
            <limit effort="300" velocity="1" lower="${-M_PI}" upper="${M_PI}" />
        </joint>

        <!-- /////////////////////////////////   LINK3  ///////////////////////////////////////////////////// -->
        <link name="link3" >
            <visual>
                <origin xyz="0 0 -${link3_length/2}" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link3_radius}" length="${link3_length}"/>
                </geometry>
                <material name="Blue" />
            </visual>
            <collision>
                <origin xyz="0 0 -${link3_length/2}" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link3_radius}" length="${link3_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link3_mass}" r="${link3_radius}" h="${link3_length}"/>
        </link>

        <joint name="joint4" type="revolute">
            <parent link="link3"/>
            <child link="link4"/>
            <origin xyz="0.0 0.0 -${link3_length}" rpy="0 ${M_PI/2} ${M_PI}" />
            <axis xyz="1 0 0" />
            <limit effort="300" velocity="1" lower="${-M_PI}" upper="${M_PI}" />
        </joint>

        <!-- ///////////////////////////////////   LINK4  //////////////////////////////////////////////// -->
        <link name="link4" >
            <visual>
                <origin xyz="${link4_length/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <cylinder radius="${link4_radius}" length="${link4_length}"/>
                </geometry>
                <material name="Black" />
            </visual>
            <collision>
                <origin xyz="${link4_length/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <cylinder radius="${link4_radius}" length="${link4_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link4_mass}" r="${link4_radius}" h="${link4_length}"/>
        </link>

        <joint name="joint5" type="revolute">
            <parent link="link4"/>
            <child link="link5"/>
            <origin xyz="${link4_length} 0.0 0.0" rpy="0 ${M_PI/2} 0" />
            <axis xyz="1 0 0" />
            <limit effort="300" velocity="1" lower="${-M_PI}" upper="${M_PI}" />
        </joint>

        <!-- //////////////////////////////////   LINK5  ///////////////////////////////////////////////// -->
        <link name="link5">
            <visual>
                <origin xyz="0 0 ${link4_length/2}" rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link5_radius}" length="${link5_length}"/>
                </geometry>
                <material name="White" />
            </visual>
            <collision>
                <origin xyz="0 0 ${link4_length/2} " rpy="0 0 0" />
                <geometry>
                    <cylinder radius="${link5_radius}" length="${link5_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link5_mass}" r="${link5_radius}" h="${link5_length}"/>
        </link>

        <joint name="joint6" type="revolute">
            <parent link="link5"/>
            <child link="link6"/>
            <origin xyz="0 0 ${link4_length}" rpy="${1.5*M_PI} -${M_PI/2} 0" />
            <axis xyz="1 0 0" />
            <limit effort="300" velocity="1" lower="${-2*M_PI}" upper="${2*M_PI}" />
        </joint>

        <!-- ////////////////////////////////   LINK6  ///////////////////////////////////////////////// -->
        <link name="link6">
            <visual>
                <origin xyz="${link6_length/2} 0 0 " rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <cylinder radius="${link6_radius}" length="${link6_length}"/>
                </geometry>
                <material name="Blue" />
            </visual>
            <collision>
                <origin xyz="${link6_length/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <cylinder radius="${link6_radius}" length="${link6_length}"/>
                </geometry>
            </collision>
            <cylinder_inertial_matrix m="${link6_mass}" r="${link6_radius}" h="${link6_length}"/>
        </link>

        <joint name="finger_joint1" type="prismatic">
            <parent link="link6"/>
            <child link="gripper_finger_link1"/>
            <origin xyz="${link6_length} -0.03 0" rpy="0 0 0" />
            <axis xyz="0 1 0" />
            <limit effort="100" lower="0" upper="0.06" velocity="0.02"/>
        </joint>

        <!-- //////////////////////////////////////   gripper   ////////////////////////////////////////////// -->
        <!-- LEFT GRIPPER AFT LINK -->
        <link name="gripper_finger_link1">
            <visual>
                <origin xyz="${gripper_height/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <box size="${gripper_length} ${gripper_width} ${gripper_height}" />
                </geometry>
                <material name="White" />
            </visual>
            <collision>
                <origin xyz="${gripper_height/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <box size="${gripper_length} ${gripper_width} ${gripper_height}" />
                </geometry>
            </collision>
            <box_inertial_matrix m="${gripper_mass}" w="${gripper_width}" h="${gripper_height}" d="${gripper_length}"/>
        </link>

        <joint name="finger_joint2" type="fixed">
            <parent link="link6"/>
            <child link="gripper_finger_link2"/>
            <origin xyz="${link6_length} 0.03 0" rpy="0 0 0" />
        </joint>

        <!-- RIGHT GRIPPER AFT LINK -->
        <link name="gripper_finger_link2">
            <visual>
                <origin xyz="${gripper_height/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <box size="${gripper_length} ${gripper_width} ${gripper_height}" />
                </geometry>
                <material name="White" />
            </visual>
            <collision>
                <origin xyz="${gripper_height/2} 0 0" rpy="0 ${M_PI/2} 0" />
                <geometry>
                    <box size="${gripper_length} ${gripper_width} ${gripper_height}" />
                </geometry>
            </collision>
            <box_inertial_matrix m="${gripper_mass}" w="${gripper_width}" h="${gripper_height}" d="${gripper_length}"/>
        </link>

        <!-- Grasping frame -->
        <link name="grasping_frame"/>

        <joint name="grasping_frame_joint" type="fixed">
            <parent link="link6"/>
            <child link="grasping_frame"/>
            <origin xyz="${gripper_height} 0 0" rpy="0 0 0"/>
        </joint>



注意:可以看到其中joint1和joint4的旋转轴和其他的不同,是因为后面在moveit中通过拖拽末端设置目标位姿时,必须至少包含2个这种旋转joint才能实现任意拖拽,否则机械臂是不能被拖动的。



最后,为每一个joint添加一个硬件仿真接口:

 <!-- Transmissions for ROS Control -->
        <xacro:macro name="transmission_block" params="joint_name">
            <transmission name="${joint_name}_trans">
                <type>transmission_interface/SimpleTransmission</type>
                <joint name="${joint_name}">
                    <hardwareInterface>hardware_interface/PositionJointInterface</hardwareInterface>
                </joint>
                <actuator name="${joint_name}_motor">
                    <hardwareInterface>hardware_interface/PositionJointInterface</hardwareInterface>
                    <mechanicalReduction>1</mechanicalReduction>
                </actuator>
            </transmission>
        </xacro:macro>

        <xacro:transmission_block joint_name="joint1"/>
        <xacro:transmission_block joint_name="joint2"/>
        <xacro:transmission_block joint_name="joint3"/>
        <xacro:transmission_block joint_name="joint4"/>
        <xacro:transmission_block joint_name="joint5"/>
        <xacro:transmission_block joint_name="joint6"/>
        <xacro:transmission_block joint_name="finger_joint1"/>

        <!-- ros_control plugin -->
        <gazebo>
            <plugin name="gazebo_ros_control" filename="libgazebo_ros_control.so">
                <robotNamespace>/arm</robotNamespace>
            </plugin>
        </gazebo>
    </xacro:macro>



这样机械臂的模型就建立好了,还需要注意的是,机械臂底座的质量一定要大些。



2 添加一个kinect模型

虽然我们使用了一个深度相机,但是该教程中我们并没有使用深度话题,仅仅使用了RGB图像。

<xacro:property name="deg_to_rad" value="0.01745329251994329577"/>
 <!-- kinect -->
    <joint name="kinect_joint" type="fixed">
        <origin xyz="0.1 0 0.8" rpy="0 ${75.0 * deg_to_rad} 0" />
        <parent link="base_link"/>
        <child link="kinect_link"/>
    </joint>

    <xacro:kinect_camera prefix="kinect"/>



最终效果如图所示:

ROS机械臂控制之跟踪二维码



3 配置二维码识别包

需要使用ros的ar_track_alvar包。



首先安装:

sudo apt-get install ros-melodic-ar-track-alvar //替换成自己的ROS版本



之后,创建一个launch文件配置ar_track_alvar节点的内部参数:

<launch>
    <arg name="marker_size" default="9" />
    <arg name="max_new_marker_error" default="0.08" />
    <arg name="max_track_error" default="0.2" />
    <arg name="cam_image_topic" default="/kinect/rgb/image_raw" />
    <arg name="cam_info_topic" default="/kinect/rgb/camera_info" />
    <arg name="output_frame" default="/base_link" />

    <node name="ar_track_alvar" pkg="ar_track_alvar" type="individualMarkersNoKinect" respawn="false" output="screen">
        <param name="marker_size"           type="double" value="$(arg marker_size)" />
        <param name="max_new_marker_error"  type="double" value="$(arg max_new_marker_error)" />
        <param name="max_track_error"       type="double" value="$(arg max_track_error)" />
        <param name="output_frame"          type="string" value="$(arg output_frame)" />

        <remap from="camera_image"  to="$(arg cam_image_topic)" />
        <remap from="camera_info"   to="$(arg cam_info_topic)" />
    </node>
</launch>



注意:marker_size是二维码的大小,单位是cm,还需要修改launch文件中的相机话题部分,其中out_frame是输出二维码pose时候参考的坐标系,这里参考的是base_link。


运行launch文件效果如下,可以看到在rviz中,已经检测到了二维码。

ROS机械臂控制之跟踪二维码



查看pose的话题消息:

rostopic echo /ar_pose_marker



ROS机械臂控制之跟踪二维码



数据包含了三维坐标值和四元数。



4 在gazebo中添加二维码模型

我直接提供了一个ar_track的二维码模型下载,ID=0,尺寸是10厘米。

链接: https://pan.baidu.com/s/1n_eIhEIaDxaboZfK8IgwqQ

密码: mlht


将这个模型放到.gazebo/models目录下即可,在打开gazbeo后添加模型,选择ar_track_mark0,如图所示:

ROS机械臂控制之跟踪二维码



5 编写机械臂控制程序

本教程使用python编程。


注意,此时你已经将你的机械臂模型通过moveit_setup_assistant进行了配置,若不熟悉,请参考古月学院的课程:MoveIt可视化配置及仿真指南 或古月居的资料:ROS探索总结(六十三)



完整程序如下:

#!/usr/bin/env python
# -*- coding: utf-8 -*-
import rospy, sys
import moveit_commander
import tf
import threading
from moveit_msgs.msg import RobotTrajectory
from trajectory_msgs.msg import JointTrajectoryPoint
from geometry_msgs.msg import PoseStamped, Pose
from ar_track_alvar_msgs.msg import AlvarMarkers,AlvarMarker

x = 0
y = 0
z = 0
ox = 0
oy = 0
oz = 0
zw = 0

# 初始化move_group的API
moveit_commander.roscpp_initialize(sys.argv)
# 初始化需要使用move group控制的机械臂中的arm group
arm = moveit_commander.MoveGroupCommander('arm')
# 初始化需要使用move group控制的机械臂中的gripper group
gripper = moveit_commander.MoveGroupCommander('gripper')
# 获取终端link的名称
end_effector_link = arm.get_end_effector_link()
# 设置目标位置所使用的参考坐标系
reference_frame = 'base_link'
arm.set_pose_reference_frame(reference_frame)
# 当运动规划失败后,允许重新规划
arm.allow_replanning(True)
# 设置位置(单位:米)和姿态(单位:弧度)的允许误差
arm.set_goal_position_tolerance(0.01)
arm.set_goal_orientation_tolerance(0.05)
gripper.set_goal_joint_tolerance(0.001)
# 控制机械臂先回到初始化位置
#arm.set_named_target('home')
#arm.go()
# 设置机器臂当前的状态作为运动初始状态
arm.set_start_state_to_current_state()
target_pose = PoseStamped()
a = 1
def Listener():
        rospy.init_node('listener', anonymous=True)
        rospy.Subscriber("/ar_pose_marker",AlvarMarkers,ar_pose)
    rospy.spin()
def ar_pose(data):
        x = data.markers[0].pose.pose.position.x
        y = data.markers[0].pose.pose.position.y
        z = data.markers[0].pose.pose.position.z
       ox = data.markers[0].pose.pose.orientation.x
        oy = data.markers[0].pose.pose.orientation.y
        oz = data.markers[0].pose.pose.orientation.z
        ow = data.markers[0].pose.pose.orientation.w

        target_pose.header.frame_id = reference_frame
        target_pose.header.stamp = rospy.Time.now()
        target_pose.pose.position.x =  x-0.08
        target_pose.pose.position.y = y
        target_pose.pose.position.z = z+0.03
        target_pose.pose.orientation.x = 0.926402
        target_pose.pose.orientation.y = 0.000348296
        target_pose.pose.orientation.z = -0.376537
        target_pose.pose.orientation.w = -0.0001816
        print(target_pose)
        # 设置机械臂终端运动的目标位姿
        arm.set_pose_target(target_pose, end_effector_link)
        arm.go()
        global a
        a+=1
        print(" count ",a)
     # 关闭并退出moveit
        #moveit_commander.roscpp_shutdown()
        #moveit_commander.os._exit(0)
        arm.clear_pose_targets()
        print("清除")
if __name__ == "__main__":
    Listener()



运行效果如下:



注意:arm.go()函数是一个阻塞函数,若不添加下面的arm.clear_pose_targets()则控制器中的pose将不会更新,导致机械臂停留在第一次执行后的位置不变



程序里,我指定了四元数,这个数值是我期待的一个末端抓取所用的位姿,三维坐标也手动添加了一下偏差,是为了避免末端遮挡二维码导致kinect无法正常检测二维码。


开心洋葱 , 版权所有丨如未注明 , 均为原创丨未经授权请勿修改 , 转载请注明ROS机械臂控制之跟踪二维码
喜欢 (0)

您必须 登录 才能发表评论!

加载中……
