容器编排系统K8s之HPA资源

docker Linux-1874 1303次浏览 0个评论

  前文我们了解了用Prometheus监控k8s上的节点和pod资源,回顾请参考:https://www.cnblogs.com/qiuhom-1874/p/14287942.html;今天我们来了解下k8s上的HPA资源的使用;

  HPA的全称是Horizontal Pod Autoscaler,从字面意思理解它就是水平pod自动伸缩器;简单讲HPA的主要作用是根据指定的指标数据,监控对应的pod控制器,一旦对应pod控制器下的pod的对应指标数据达到我们定义的阀值,即HPA就会被触发,它会根据对应指标数据的值来扩展/缩减对应pod副本数量;扩展和缩减都是有上下限的,当pod数量达到上限,即便指标数据还是超过了我们定义的阀值它也不会再扩展,对于下线默认不指定就是为1;下限和上限都是一样的逻辑,即便一个访问都没有,它会保持最低有多少个pod运行;需注意hpa只能用于监控可扩缩的pod控制器,对DaemonSet类型控制器不支持;

  在k8s上HPA有两个版本v1和v2;v1只支持根据cpu这个指标数据来自动扩展/缩减pod数量;V2支持根据自定义指标数量来自动扩展/缩减pod数量;HPA是k8s上的标准资源,我们可以通过命令或资源清单的方式去创建它;

  使用命令创建HPA资源的使用语法格式

Usage:
  kubectl autoscale (-f FILENAME | TYPE NAME | TYPE/NAME) [--min=MINPODS] --max=MAXPODS [--cpu-percent=CPU] [options]

  提示:默认不指定hpa的名称,它会同对应的pod控制名称相同;–min选项用于指定对应pod副本最低数量,默认不指定其值为1,–max用于指定pod最大副本数量;–cpu-percent选项用于指定对应pod的cpu资源的占用比例,该占用比例是同对应pod的资源限制做比较;

  示例:使用命令创建v1版本的hpa资源

  使用deploy控制器创建pod资源

[root@master01 ~]# cat myapp.yaml
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
  namespace: default
  labels:
    app: myapp
spec:
  replicas: 2
  selector:
    matchLabels:
      app: myapp
  template:
    metadata:
      name: myapp-pod
      labels:
        app: myapp
    spec:
      containers:
      - name: myapp
        image: ikubernetes/myapp:v1
        resources:
          requests:
            cpu: 50m
            memory: 64Mi
          limits:
            cpu: 50m
            memory: 64Mi
---
apiVersion: v1
kind: Service
metadata:
  name: myapp-svc
  labels:
    app: myapp
  namespace: default
spec:
  selector:
    app: myapp
  ports:
  - name: http
    port: 80
    targetPort: 80
  type: NodePort
[root@master01 ~]#

  应用资源清单

[root@master01 ~]# kubectl apply -f myapp.yaml
deployment.apps/myapp created
service/myapp-svc created
[root@master01 ~]# kubectl get pods
NAME                     READY   STATUS    RESTARTS   AGE
myapp-779867bcfc-657qr   1/1     Running   0          6s
myapp-779867bcfc-txvj8   1/1     Running   0          6s
[root@master01 ~]# kubectl get svc
NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)        AGE
kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP        8d
myapp-svc    NodePort    10.111.14.219   <none>        80:31154/TCP   13s
[root@master01 ~]#

  查看pod的资源占比情况

[root@master01 ~]# kubectl top pods
NAME                     CPU(cores)   MEMORY(bytes)
myapp-779867bcfc-657qr   0m           3Mi
myapp-779867bcfc-txvj8   0m           3Mi
[root@master01 ~]#

  提示:现在没有访问对应pod,其cpu指标为0;

  使用命令创建hpa资源,监控myapp deploy,指定对应pod的cpu资源使用率达到50%就触发hpa

[root@master01 ~]# kubectl autoscale deploy myapp --min=2 --max=10 --cpu-percent=50
horizontalpodautoscaler.autoscaling/myapp autoscaled
[root@master01 ~]# kubectl get hpa
NAME    REFERENCE          TARGETS         MINPODS   MAXPODS   REPLICAS   AGE
myapp   Deployment/myapp   <unknown>/50%   2         10        0          10s
[root@master01 ~]# kubectl describe hpa/myapp
Name:                                                  myapp
Namespace:                                             default
Labels:                                                <none>
Annotations:                                           <none>
CreationTimestamp:                                     Mon, 18 Jan 2021 15:26:49 +0800
Reference:                                             Deployment/myapp
Metrics:                                               ( current / target )
  resource cpu on pods  (as a percentage of request):  0% (0) / 50%
Min replicas:                                          2
Max replicas:                                          10
Deployment pods:                                       2 current / 2 desired
Conditions:
  Type            Status  Reason               Message
  ----            ------  ------               -------
  AbleToScale     True    ScaleDownStabilized  recent recommendations were higher than current one, applying the highest recent recommendation
  ScalingActive   True    ValidMetricFound     the HPA was able to successfully calculate a replica count from cpu resource utilization (percentage of request)
  ScalingLimited  False   DesiredWithinRange   the desired count is within the acceptable range
Events:           <none>
[root@master01 ~]#

  验证:使用ab压测工具,对pod进行压力访问,看看对应pod cpu资源使用率大于50%,对应pod是否会扩展?

  安装ab工具

 yum install httpd-tools -y

  使用外部主机对pod svc 进行压力访问

容器编排系统K8s之HPA资源

  查看pod的资源占比情况

[root@master01 ~]# kubectl top pods
NAME                     CPU(cores)   MEMORY(bytes)
myapp-779867bcfc-657qr   51m          4Mi
myapp-779867bcfc-txvj8   34m          4Mi
[root@master01 ~]#

  提示:可以看到对应pod的cpu资源都大于限制的资源上限的50%;这里需要注意hpa扩展pod它有一定的延迟,不是立刻马上就扩展;

  查看对应hpa资源的详情

容器编排系统K8s之HPA资源

  提示:hpa详情告诉我们对应pod扩展到7个;

  查看pod数量是否被扩展到7个?

[root@master01 ~]# kubectl get pods
NAME                     READY   STATUS    RESTARTS   AGE
myapp-779867bcfc-657qr   1/1     Running   0          16m
myapp-779867bcfc-7c4dt   1/1     Running   0          3m27s
myapp-779867bcfc-b2jmn   1/1     Running   0          3m27s
myapp-779867bcfc-fmw7v   1/1     Running   0          2m25s
myapp-779867bcfc-hxhj2   1/1     Running   0          2m25s
myapp-779867bcfc-txvj8   1/1     Running   0          16m
myapp-779867bcfc-xvh58   1/1     Running   0          2m25s
[root@master01 ~]#

  提示:可以看到对应pod被控制到7个;

  查看对应pod的资源占比是否还高于限制的50%?

[root@master01 ~]# kubectl top pods
NAME                     CPU(cores)   MEMORY(bytes)
myapp-779867bcfc-657qr   49m          4Mi
myapp-779867bcfc-7c4dt   25m          4Mi
myapp-779867bcfc-b2jmn   36m          4Mi
myapp-779867bcfc-fmw7v   42m          4Mi
myapp-779867bcfc-hxhj2   46m          3Mi
myapp-779867bcfc-txvj8   21m          4Mi
myapp-779867bcfc-xvh58   49m          4Mi
[root@master01 ~]#

  提示:可以看到对应pod的cpu使用率还是高于限制的50%,说明扩展到pod数量不能够响应对应的请求,此时hpa还会扩展;

  查看hpa详情,看看是否又一次扩展pod的数量?

容器编排系统K8s之HPA资源

  提示:可以看到对应pod被扩展到10个,但是对应cpu资源使用率为94%,此时pod数量已经到达上限,即便对应指标数据还是大于指定的阀值,它也不会扩展;

  查看pod数量是否为10个?

[root@master01 ~]# kubectl get pods
NAME                     READY   STATUS    RESTARTS   AGE
myapp-779867bcfc-57zw7   1/1     Running   0          5m39s
myapp-779867bcfc-657qr   1/1     Running   0          23m
myapp-779867bcfc-7c4dt   1/1     Running   0          10m
myapp-779867bcfc-b2jmn   1/1     Running   0          10m
myapp-779867bcfc-dvq6k   1/1     Running   0          5m39s
myapp-779867bcfc-fmw7v   1/1     Running   0          9m45s
myapp-779867bcfc-hxhj2   1/1     Running   0          9m45s
myapp-779867bcfc-n8lmf   1/1     Running   0          5m39s
myapp-779867bcfc-txvj8   1/1     Running   0          23m
myapp-779867bcfc-xvh58   1/1     Running   0          9m45s
[root@master01 ~]#

  停止压测,看看对应pod是否会缩减到最低pod数量为2个呢?

[root@master01 ~]# kubectl get pods
NAME                     READY   STATUS    RESTARTS   AGE
myapp-779867bcfc-57zw7   1/1     Running   0          8m8s
myapp-779867bcfc-657qr   1/1     Running   0          26m
myapp-779867bcfc-7c4dt   1/1     Running   0          13m
myapp-779867bcfc-b2jmn   1/1     Running   0          13m
myapp-779867bcfc-dvq6k   1/1     Running   0          8m8s
myapp-779867bcfc-fmw7v   1/1     Running   0          12m
myapp-779867bcfc-hxhj2   1/1     Running   0          12m
myapp-779867bcfc-n8lmf   1/1     Running   0          8m8s
myapp-779867bcfc-txvj8   1/1     Running   0          26m
myapp-779867bcfc-xvh58   1/1     Running   0          12m
[root@master01 ~]# kubectl top pods
NAME                     CPU(cores)   MEMORY(bytes)
myapp-779867bcfc-57zw7   0m           4Mi
myapp-779867bcfc-657qr   0m           4Mi
myapp-779867bcfc-7c4dt   7m           4Mi
myapp-779867bcfc-b2jmn   0m           4Mi
myapp-779867bcfc-dvq6k   0m           4Mi
myapp-779867bcfc-fmw7v   0m           4Mi
myapp-779867bcfc-hxhj2   3m           3Mi
myapp-779867bcfc-n8lmf   10m          4Mi
myapp-779867bcfc-txvj8   0m           4Mi
myapp-779867bcfc-xvh58   0m           4Mi
[root@master01 ~]#

  提示:pod缩减也是不会立刻执行;从上面信息可以看到停止压测对应pod的cpu资源使用率都降下来了;

  再次查看对应pod数量

[root@master01 ~]# kubectl top pods
NAME                     CPU(cores)   MEMORY(bytes)
myapp-779867bcfc-57zw7   0m           4Mi
myapp-779867bcfc-657qr   0m           4Mi
[root@master01 ~]# kubectl get pods
NAME                     READY   STATUS    RESTARTS   AGE
myapp-779867bcfc-57zw7   1/1     Running   0          13m
myapp-779867bcfc-657qr   1/1     Running   0          31m
[root@master01 ~]#

  提示:可以看到对应pod缩减到最低pod副本数量;

  查看hpa的详情

容器编排系统K8s之HPA资源

  提示:可以看到对应pod的cpu使用率小于50%,它会隔一段时间就缩减对应pod;

  示例:使用资源清单定义hpa资源

[root@master01 ~]# cat hpa-demo.yaml
apiVersion: autoscaling/v1
kind: HorizontalPodAutoscaler
metadata:
  name: hpa-demo
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: myapp
  minReplicas: 2
  maxReplicas: 10
  targetCPUUtilizationPercentage: 50
[root@master01 ~]#

  提示:以上是hpa v1的资源清单定义示例,其中targetCPUUtilizationPercentage用于指定cpu资源使用率阀值,50表示50%,即达到pod上限的50%对应hpa就会被触发;

  应用清单

[root@master01 ~]# kubectl apply -f hpa-demo.yaml
horizontalpodautoscaler.autoscaling/hpa-demo created
[root@master01 ~]# kubectl get hpa
NAME       REFERENCE          TARGETS         MINPODS   MAXPODS   REPLICAS   AGE
hpa-demo   Deployment/myapp   <unknown>/50%   2         10        0          8s
myapp      Deployment/myapp   0%/50%          2         10        2          35m
[root@master01 ~]# kubectl describe hpa/hpa-demo
Name:                                                  hpa-demo
Namespace:                                             default
Labels:                                                <none>
Annotations:                                           <none>
CreationTimestamp:                                     Mon, 18 Jan 2021 16:02:25 +0800
Reference:                                             Deployment/myapp
Metrics:                                               ( current / target )
  resource cpu on pods  (as a percentage of request):  0% (0) / 50%
Min replicas:                                          2
Max replicas:                                          10
Deployment pods:                                       2 current / 2 desired
Conditions:
  Type            Status  Reason               Message
  ----            ------  ------               -------
  AbleToScale     True    ScaleDownStabilized  recent recommendations were higher than current one, applying the highest recent recommendation
  ScalingActive   True    ValidMetricFound     the HPA was able to successfully calculate a replica count from cpu resource utilization (percentage of request)
  ScalingLimited  False   DesiredWithinRange   the desired count is within the acceptable range
Events:           <none>
[root@master01 ~]#

  提示:可以看到使用命令创建hpa和使用资源清单创建hpa其创建出来的hpa都是一样的;以上是hpa v1的使用示例和相关说明;使用命令创建hpa,只能创建v1的hpa;v2必须使用资源清单,明确指定对应hpa的群组版本;

  使用自定义资源指标定义hpa

  部署自定义资源指标服务器

  下载部署清单

[root@master01 ~]# mkdir custom-metrics-server
[root@master01 ~]# cd custom-metrics-server
[root@master01 custom-metrics-server]# git clone https://github.com/stefanprodan/k8s-prom-hpa
Cloning into 'k8s-prom-hpa'...
remote: Enumerating objects: 223, done.
remote: Total 223 (delta 0), reused 0 (delta 0), pack-reused 223
Receiving objects: 100% (223/223), 102.23 KiB | 14.00 KiB/s, done.
Resolving deltas: 100% (117/117), done.
[root@master01 custom-metrics-server]# ls
k8s-prom-hpa
[root@master01 custom-metrics-server]#

  查看custom-metrics-server的部署清单

[root@master01 custom-metrics-server]# cd k8s-prom-hpa/
[root@master01 k8s-prom-hpa]# ls
custom-metrics-api  diagrams  ingress  LICENSE  Makefile  metrics-server  namespaces.yaml  podinfo  prometheus  README.md
[root@master01 k8s-prom-hpa]# cd custom-metrics-api/
[root@master01 custom-metrics-api]# ls
custom-metrics-apiserver-auth-delegator-cluster-role-binding.yaml   custom-metrics-apiservice.yaml
custom-metrics-apiserver-auth-reader-role-binding.yaml              custom-metrics-cluster-role.yaml
custom-metrics-apiserver-deployment.yaml                            custom-metrics-config-map.yaml
custom-metrics-apiserver-resource-reader-cluster-role-binding.yaml  custom-metrics-resource-reader-cluster-role.yaml
custom-metrics-apiserver-service-account.yaml                       hpa-custom-metrics-cluster-role-binding.yaml
custom-metrics-apiserver-service.yaml
[root@master01 custom-metrics-api]# cat custom-metrics-apiserver-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: custom-metrics-apiserver
  name: custom-metrics-apiserver
  namespace: monitoring
spec:
  replicas: 1
  selector:
    matchLabels:
      app: custom-metrics-apiserver
  template:
    metadata:
      labels:
        app: custom-metrics-apiserver
      name: custom-metrics-apiserver
    spec:
      serviceAccountName: custom-metrics-apiserver
      containers:
      - name: custom-metrics-apiserver
        image: quay.io/coreos/k8s-prometheus-adapter-amd64:v0.4.1
        args:
        - /adapter
        - --secure-port=6443
        - --tls-cert-file=/var/run/serving-cert/serving.crt
        - --tls-private-key-file=/var/run/serving-cert/serving.key
        - --logtostderr=true
        - --prometheus-url=http://prometheus.monitoring.svc:9090/
        - --metrics-relist-interval=30s
        - --v=10
        - --config=/etc/adapter/config.yaml
        ports:
        - containerPort: 6443
        volumeMounts:
        - mountPath: /var/run/serving-cert
          name: volume-serving-cert
          readOnly: true
        - mountPath: /etc/adapter/
          name: config
          readOnly: true
      volumes:
      - name: volume-serving-cert
        secret:
          secretName: cm-adapter-serving-certs
      - name: config
        configMap:
          name: adapter-config
[root@master01 custom-metrics-api]#

  提示:上述清单中明确定义了把自定义指标服务器部署到monitoring名称空间下,对应server的启动还挂在了secret证书;所以应用上述清单前,我们要先创建名称空间和secret;在创建secret前还要先准备好证书和私钥;这里还需要注意custom-metrics-server是连接Prometheus server,把对应自定义数据通过apiservice注册到对应原生apiserver上,供k8s组件使用,所以这里要注意对应Prometheus的地址;

  创建monitoring名称空间

[root@master01 custom-metrics-api]# cd ..
[root@master01 k8s-prom-hpa]# ls
custom-metrics-api  diagrams  ingress  LICENSE  Makefile  metrics-server  namespaces.yaml  podinfo  prometheus  README.md
[root@master01 k8s-prom-hpa]# cat namespaces.yaml
---
apiVersion: v1
kind: Namespace
metadata:
  name: monitoring


[root@master01 k8s-prom-hpa]# kubectl apply -f namespaces.yaml
namespace/monitoring created
[root@master01 k8s-prom-hpa]# kubectl get ns
NAME                   STATUS   AGE
default                Active   41d
ingress-nginx          Active   27d
kube-node-lease        Active   41d
kube-public            Active   41d
kube-system            Active   41d
kubernetes-dashboard   Active   16d
mongodb                Active   4d20h
monitoring             Active   4s
[root@master01 k8s-prom-hpa]#

  生成serving.key和serving.csr

[root@master01 k8s-prom-hpa]# cd /etc/kubernetes/pki/
[root@master01 pki]# ls
apiserver.crt              apiserver.key                 ca.crt  etcd                front-proxy-client.crt  sa.pub   tom.key
apiserver-etcd-client.crt  apiserver-kubelet-client.crt  ca.key  front-proxy-ca.crt  front-proxy-client.key  tom.crt
apiserver-etcd-client.key  apiserver-kubelet-client.key  ca.srl  front-proxy-ca.key  sa.key                  tom.csr
[root@master01 pki]# openssl genrsa -out serving.key 2048
Generating RSA private key, 2048 bit long modulus
.............................................................................................................................................................+++
..............................+++
e is 65537 (0x10001)
[root@master01 pki]# openssl req -new -key ./serving.key -out ./serving.csr -subj "/CN=serving"
[root@master01 pki]# ll
total 80
-rw-r--r-- 1 root root 1277 Dec  8 14:38 apiserver.crt
-rw-r--r-- 1 root root 1135 Dec  8 14:38 apiserver-etcd-client.crt
-rw------- 1 root root 1679 Dec  8 14:38 apiserver-etcd-client.key
-rw------- 1 root root 1679 Dec  8 14:38 apiserver.key
-rw-r--r-- 1 root root 1143 Dec  8 14:38 apiserver-kubelet-client.crt
-rw------- 1 root root 1679 Dec  8 14:38 apiserver-kubelet-client.key
-rw-r--r-- 1 root root 1066 Dec  8 14:38 ca.crt
-rw------- 1 root root 1675 Dec  8 14:38 ca.key
-rw-r--r-- 1 root root   17 Jan 17 13:03 ca.srl
drwxr-xr-x 2 root root  162 Dec  8 14:38 etcd
-rw-r--r-- 1 root root 1078 Dec  8 14:38 front-proxy-ca.crt
-rw------- 1 root root 1675 Dec  8 14:38 front-proxy-ca.key
-rw-r--r-- 1 root root 1103 Dec  8 14:38 front-proxy-client.crt
-rw------- 1 root root 1679 Dec  8 14:38 front-proxy-client.key
-rw------- 1 root root 1679 Dec  8 14:38 sa.key
-rw------- 1 root root  451 Dec  8 14:38 sa.pub
-rw-r--r-- 1 root root  887 Jan 18 16:54 serving.csr
-rw-r--r-- 1 root root 1679 Jan 18 16:54 serving.key
-rw-r--r-- 1 root root  993 Dec 30 00:29 tom.crt
-rw-r--r-- 1 root root  907 Dec 30 00:27 tom.csr
-rw-r--r-- 1 root root 1675 Dec 30 00:21 tom.key
[root@master01 pki]#

  用kubenetes CA的key和证书为custom-metrics-server签署证书

[root@master01 pki]# openssl x509 -req -in serving.csr -CA /etc/kubernetes/pki/ca.crt -CAkey /etc/kubernetes/pki/ca.key -CAcreateserial -out serving.crt -days 3650
Signature ok
subject=/CN=serving
Getting CA Private Key
[root@master01 pki]# ll serving.crt
-rw-r--r-- 1 root root 977 Jan 18 16:55 serving.crt
[root@master01 pki]#

  在monitoring名称空间下创建secret资源

[root@master01 pki]# kubectl create secret generic cm-adapter-serving-certs --from-file=./serving.key --from-file=./serving.crt -n monitoring
secret/cm-adapter-serving-certs created
[root@master01 pki]# kubectl get secret -n monitoring
NAME                       TYPE                                  DATA   AGE
cm-adapter-serving-certs   Opaque                                2      10s
default-token-k64tz        kubernetes.io/service-account-token   3      2m27s
[root@master01 pki]# kubectl describe secret/cm-adapter-serving-certs -n monitoring
Name:         cm-adapter-serving-certs
Namespace:    monitoring
Labels:       <none>
Annotations:  <none>

Type:  Opaque

Data
====
serving.crt:  977 bytes
serving.key:  1679 bytes
[root@master01 pki]#

  提示:这里一定要使用generic类型创建secret,保持对应的名称为serving.key和serving.crt;创建secret的名称,必须同custom-metrics部署清单中的名称保持一致;

  部署prometheus

[root@master01 pki]# cd /root/custom-metrics-server/k8s-prom-hpa/prometheus/
[root@master01 prometheus]# ls
prometheus-cfg.yaml  prometheus-dep.yaml  prometheus-rbac.yaml  prometheus-svc.yaml
[root@master01 prometheus]# cat prometheus-dep.yaml
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: prometheus
  namespace: monitoring
spec:
  replicas: 1
  selector:
    matchLabels:
      app: prometheus
  template:
    metadata:
      labels:
        app: prometheus
      annotations:
        prometheus.io/scrape: 'false'
    spec:
      serviceAccountName: prometheus
      containers:
      - name: prometheus
        image: prom/prometheus:v2.1.0
        imagePullPolicy: Always
        command:
          - prometheus
          - --config.file=/etc/prometheus/prometheus.yml
          - --storage.tsdb.retention=1h
        ports:
        - containerPort: 9090
          protocol: TCP
        resources:
          limits:
            memory: 2Gi
        volumeMounts:
        - mountPath: /etc/prometheus/prometheus.yml
          name: prometheus-config
          subPath: prometheus.yml
      volumes:
        - name: prometheus-config
          configMap:
            name: prometheus-config
            items:
              - key: prometheus.yml
                path: prometheus.yml
                mode: 0644
[root@master01 prometheus]#

  更改rbac资源清单中的群组版本为 rbac.authorization.k8s.io/v1

[root@master01 prometheus]# cat prometheus-rbac.yaml
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: prometheus
rules:
- apiGroups: [""]
  resources:
  - nodes
  - nodes/proxy
  - services
  - endpoints
  - pods
  verbs: ["get", "list", "watch"]
- apiGroups:
  - extensions
  resources:
  - ingresses
  verbs: ["get", "list", "watch"]
- nonResourceURLs: ["/metrics"]
  verbs: ["get"]
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: prometheus
  namespace: monitoring
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: prometheus
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: prometheus
subjects:
- kind: ServiceAccount
  name: prometheus
  namespace: monitoring
[root@master01 prometheus]#

  应用prometheus目录下的所有资源清单

[root@master01 prometheus]# kubectl apply -f .
configmap/prometheus-config created
deployment.apps/prometheus created
clusterrole.rbac.authorization.k8s.io/prometheus created
serviceaccount/prometheus created
clusterrolebinding.rbac.authorization.k8s.io/prometheus created
service/prometheus created
[root@master01 prometheus]# kubectl get pods -n monitoring
NAME                          READY   STATUS    RESTARTS   AGE
prometheus-5c5dc6d6d4-drrht   1/1     Running   0          26s
[root@master01 prometheus]# kubectl get svc -n monitoring
NAME         TYPE       CLUSTER-IP    EXTERNAL-IP   PORT(S)          AGE
prometheus   NodePort   10.99.1.110   <none>        9090:31190/TCP   35s
[root@master01 prometheus]#

  部署自定义指标服务,应用custom-metrics-server目录下的所有资源清单

[root@master01 prometheus]# cd ../custom-metrics-api/
[root@master01 custom-metrics-api]# ls
custom-metrics-apiserver-auth-delegator-cluster-role-binding.yaml   custom-metrics-apiservice.yaml
custom-metrics-apiserver-auth-reader-role-binding.yaml              custom-metrics-cluster-role.yaml
custom-metrics-apiserver-deployment.yaml                            custom-metrics-config-map.yaml
custom-metrics-apiserver-resource-reader-cluster-role-binding.yaml  custom-metrics-resource-reader-cluster-role.yaml
custom-metrics-apiserver-service-account.yaml                       hpa-custom-metrics-cluster-role-binding.yaml
custom-metrics-apiserver-service.yaml
[root@master01 custom-metrics-api]# kubectl apply -f .
clusterrolebinding.rbac.authorization.k8s.io/custom-metrics:system:auth-delegator created
rolebinding.rbac.authorization.k8s.io/custom-metrics-auth-reader created
deployment.apps/custom-metrics-apiserver created
clusterrolebinding.rbac.authorization.k8s.io/custom-metrics-resource-reader created
serviceaccount/custom-metrics-apiserver created
service/custom-metrics-apiserver created
apiservice.apiregistration.k8s.io/v1beta1.custom.metrics.k8s.io created
clusterrole.rbac.authorization.k8s.io/custom-metrics-server-resources created
configmap/adapter-config created
clusterrole.rbac.authorization.k8s.io/custom-metrics-resource-reader created
clusterrolebinding.rbac.authorization.k8s.io/hpa-controller-custom-metrics created
[root@master01 custom-metrics-api]# kubectl get pods -n monitoring
NAME                                        READY   STATUS    RESTARTS   AGE
custom-metrics-apiserver-754dfc87c7-cdhqj   1/1     Running   0          18s
prometheus-5c5dc6d6d4-drrht                 1/1     Running   0          6m9s
[root@master01 custom-metrics-api]# kubectl get svc -n monitoring
NAME                       TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)          AGE
custom-metrics-apiserver   ClusterIP   10.99.245.190   <none>        443/TCP          31s
prometheus                 NodePort    10.99.1.110     <none>        9090:31190/TCP   6m21s
[root@master01 custom-metrics-api]#

  提示:应用上述清单前,请把所有rbac.authorization.k8s.io/v1beta1更改为rbac.authorization.k8s.io/v1,把apiservice中的版本为apiregistration.k8s.io/v1;如果是1.17之前的k8s,不用修改;

  验证:查看原生apiserver是否有custom.metrics.k8s.io的群组注册进来?

[root@master01 custom-metrics-api]# kubectl api-versions|grep custom
custom.metrics.k8s.io/v1beta1
[root@master01 custom-metrics-api]#

  验证:访问对应群组,看看是否能够请求到自定义资源指标?

[root@master01 custom-metrics-api]# kubectl get --raw "/apis/metrics.k8s.io/v1beta1/" | jq .
{
  "kind": "APIResourceList",
  "apiVersion": "v1",
  "groupVersion": "metrics.k8s.io/v1beta1",
  "resources": [
    {
      "name": "nodes",
      "singularName": "",
      "namespaced": false,
      "kind": "NodeMetrics",
      "verbs": [
        "get",
        "list"
      ]
    },
    {
      "name": "pods",
      "singularName": "",
      "namespaced": true,
      "kind": "PodMetrics",
      "verbs": [
        "get",
        "list"
      ]
    }
  ]
}
[root@master01 custom-metrics-api]#

  提示:如果访问对应群组能够响应数据,表示自定义资源指标服务器没有问题;

  示例:创建podinfo pod,该pod输出http_requests资源指标

[root@master01 custom-metrics-api]# cd ..
[root@master01 k8s-prom-hpa]# ls
custom-metrics-api  diagrams  ingress  LICENSE  Makefile  metrics-server  namespaces.yaml  podinfo  prometheus  README.md
[root@master01 k8s-prom-hpa]# cd podinfo/
[root@master01 podinfo]# ls
podinfo-dep.yaml  podinfo-hpa-custom.yaml  podinfo-hpa.yaml  podinfo-ingress.yaml  podinfo-svc.yaml
[root@master01 podinfo]# cat podinfo-dep.yaml
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: podinfo
spec:
  selector:
    matchLabels:
      app: podinfo
  replicas: 2
  template:
    metadata:
      labels:
        app: podinfo
      annotations:
        prometheus.io/scrape: "true"
    spec:
      containers:
        - name: podinfod
          image: stefanprodan/podinfo:0.0.1
          imagePullPolicy: Always
          command:
            - ./podinfo
            - -port=9898
            - -logtostderr=true
            - -v=2
          volumeMounts:
            - name: metadata
              mountPath: /etc/podinfod/metadata
              readOnly: true
          ports:
            - containerPort: 9898
              protocol: TCP
          readinessProbe:
            httpGet:
              path: /readyz
              port: 9898
            initialDelaySeconds: 1
            periodSeconds: 2
            failureThreshold: 1
          livenessProbe:
            httpGet:
              path: /healthz
              port: 9898
            initialDelaySeconds: 1
            periodSeconds: 3
            failureThreshold: 2
          resources:
            requests:
              memory: "32Mi"
              cpu: "1m"
            limits:
              memory: "256Mi"
              cpu: "100m"
      volumes:
        - name: metadata
          downwardAPI:
            items:
              - path: "labels"
                fieldRef:
                  fieldPath: metadata.labels
              - path: "annotations"
                fieldRef:
                  fieldPath: metadata.annotations
[root@master01 podinfo]# cat podinfo-svc.yaml
---
apiVersion: v1
kind: Service
metadata:
  name: podinfo
  labels:
    app: podinfo
spec:
  type: NodePort
  ports:
    - port: 9898
      targetPort: 9898
      nodePort: 31198
      protocol: TCP
  selector:
    app: podinfo
[root@master01 podinfo]#

  应用资源清单

[root@master01 podinfo]# kubectl apply -f podinfo-dep.yaml,./podinfo-svc.yaml
deployment.apps/podinfo created
service/podinfo created
[root@master01 podinfo]# kubectl get svc
NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)          AGE
kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP          8d
myapp-svc    NodePort    10.111.14.219   <none>        80:31154/TCP     4h35m
podinfo      NodePort    10.111.10.211   <none>        9898:31198/TCP   17s
[root@master01 podinfo]# kubectl get pods
NAME                       READY   STATUS    RESTARTS   AGE
myapp-779867bcfc-57zw7     1/1     Running   0          4h18m
myapp-779867bcfc-657qr     1/1     Running   0          4h36m
podinfo-56874dc7f8-5rb9q   1/1     Running   0          40s
podinfo-56874dc7f8-t6jgn   1/1     Running   0          40s
[root@master01 podinfo]#

  验证:访问podinfo svc,看看对应pod是否能够正常访问?

[root@master01 podinfo]# kubectl get svc
NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)          AGE
kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP          8d
myapp-svc    NodePort    10.111.14.219   <none>        80:31154/TCP     4h37m
podinfo      NodePort    10.111.10.211   <none>        9898:31198/TCP   116s
[root@master01 podinfo]# curl 10.111.10.211:9898
runtime:
  arch: amd64
  external_ip: ""
  max_procs: "4"
  num_cpu: "4"
  num_goroutine: "9"
  os: linux
  version: go1.9.2
labels:
  app: podinfo
  pod-template-hash: 56874dc7f8
annotations:
  cni.projectcalico.org/podIP: 10.244.3.133/32
  cni.projectcalico.org/podIPs: 10.244.3.133/32
  kubernetes.io/config.seen: 2021-01-18T19:57:31.325293640+08:00
  kubernetes.io/config.source: api
  prometheus.io/scrape: "true"
environment:
  HOME: /root
  HOSTNAME: podinfo-56874dc7f8-5rb9q
  KUBERNETES_PORT: tcp://10.96.0.1:443
  KUBERNETES_PORT_443_TCP: tcp://10.96.0.1:443
  KUBERNETES_PORT_443_TCP_ADDR: 10.96.0.1
  KUBERNETES_PORT_443_TCP_PORT: "443"
  KUBERNETES_PORT_443_TCP_PROTO: tcp
  KUBERNETES_SERVICE_HOST: 10.96.0.1
  KUBERNETES_SERVICE_PORT: "443"
  KUBERNETES_SERVICE_PORT_HTTPS: "443"
  MYAPP_SVC_PORT: tcp://10.111.14.219:80
  MYAPP_SVC_PORT_80_TCP: tcp://10.111.14.219:80
  MYAPP_SVC_PORT_80_TCP_ADDR: 10.111.14.219
  MYAPP_SVC_PORT_80_TCP_PORT: "80"
  MYAPP_SVC_PORT_80_TCP_PROTO: tcp
  MYAPP_SVC_SERVICE_HOST: 10.111.14.219
  MYAPP_SVC_SERVICE_PORT: "80"
  MYAPP_SVC_SERVICE_PORT_HTTP: "80"
  PATH: /usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
  PODINFO_PORT: tcp://10.111.10.211:9898
  PODINFO_PORT_9898_TCP: tcp://10.111.10.211:9898
  PODINFO_PORT_9898_TCP_ADDR: 10.111.10.211
  PODINFO_PORT_9898_TCP_PORT: "9898"
  PODINFO_PORT_9898_TCP_PROTO: tcp
  PODINFO_SERVICE_HOST: 10.111.10.211
  PODINFO_SERVICE_PORT: "9898"
[root@master01 podinfo]#

  验证:访问apiserver,看看对应pod输出的http_requests资源指标是否能够被访问到?

[root@master01 podinfo]# kubectl get --raw "/apis/custom.metrics.k8s.io/v1beta1/namespaces/default/pods/*/http_requests" | jq .
{
  "kind": "MetricValueList",
  "apiVersion": "custom.metrics.k8s.io/v1beta1",
  "metadata": {
    "selfLink": "/apis/custom.metrics.k8s.io/v1beta1/namespaces/default/pods/%2A/http_requests"
  },
  "items": [
    {
      "describedObject": {
        "kind": "Pod",
        "namespace": "default",
        "name": "podinfo-56874dc7f8-5rb9q",
        "apiVersion": "/v1"
      },
      "metricName": "http_requests",
      "timestamp": "2021-01-18T12:01:41Z",
      "value": "911m"
    },
    {
      "describedObject": {
        "kind": "Pod",
        "namespace": "default",
        "name": "podinfo-56874dc7f8-t6jgn",
        "apiVersion": "/v1"
      },
      "metricName": "http_requests",
      "timestamp": "2021-01-18T12:01:41Z",
      "value": "888m"
    }
  ]
}
[root@master01 podinfo]#

  提示:可以看到现在用kubectl 工具可以在apiserver上访问到对应pod提供的自定义指标数据;

  示例:根据自定义指标数据,定义hpa资源

[root@master01 podinfo]# cat podinfo-hpa-custom.yaml
---
apiVersion: autoscaling/v2beta2
kind: HorizontalPodAutoscaler
metadata:
  name: podinfo
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: podinfo
  minReplicas: 2
  maxReplicas: 10
  metrics:
    - type: Pods
      pods:
        metric:
          name: http_requests
        target:
          type: AverageValue
          averageValue: 10
[root@master01 podinfo]#

  提示:使用自定义资源指标,对应hpa的群组必须为autoscale/v2beta2;对应自定义指标用metrics字段给定;type用来描述对应自定义指标数据是什么类型,pod表示是pod自身提供的自定义指标数据;上述资源清单表示引用pod自身的自定义指标数据,其名称为http_requests;对该指标数据的平均值做监控,如果对应指标平均值大于10,则触发hpa对其扩展,当对应指标数据小于10,对应hpa会对应进行缩减操作;

  应用资源清单

[root@master01 podinfo]# kubectl apply -f podinfo-hpa-custom.yaml
horizontalpodautoscaler.autoscaling/podinfo created
[root@master01 podinfo]# kubectl get hpa
NAME       REFERENCE            TARGETS        MINPODS   MAXPODS   REPLICAS   AGE
hpa-demo   Deployment/myapp     0%/50%         2         10        2          4h1m
myapp      Deployment/myapp     0%/50%         2         10        2          4h37m
podinfo    Deployment/podinfo   <unknown>/10   2         10        0          6s
[root@master01 podinfo]# kubectl describe hpa/podinfo
Name:                       podinfo
Namespace:                  default
Labels:                     <none>
Annotations:                <none>
CreationTimestamp:          Mon, 18 Jan 2021 20:04:14 +0800
Reference:                  Deployment/podinfo
Metrics:                    ( current / target )
  "http_requests" on pods:  899m / 10
Min replicas:               2
Max replicas:               10
Deployment pods:            2 current / 2 desired
Conditions:
  Type            Status  Reason               Message
  ----            ------  ------               -------
  AbleToScale     True    ScaleDownStabilized  recent recommendations were higher than current one, applying the highest recent recommendation
  ScalingActive   True    ValidMetricFound     the HPA was able to successfully calculate a replica count from pods metric http_requests
  ScalingLimited  False   DesiredWithinRange   the desired count is within the acceptable range
Events:           <none>
[root@master01 podinfo]#

  对podinfo 进行压测,看看对应hpa是否能够自动扩展?

容器编排系统K8s之HPA资源

  提示:可以看到对应pod能够被对应的hpa通过自定义指标来扩展pod数量;

  停止压测,看看对应pod是否会自动缩减至最低数量? 容器编排系统K8s之HPA资源

  提示:可以看到停止压测以后,对应的指标数据降低下来,对应的pod也随之缩减到最低副本数量;以上就是hpa v2的简单使用方式,更多示例和说明请参考官方文档https://kubernetes.io/zh/docs/tasks/run-application/horizontal-pod-autoscale/;


开心洋葱 , 版权所有丨如未注明 , 均为原创丨未经授权请勿修改 , 转载请注明容器编排系统K8s之HPA资源
喜欢 (0)

您必须 登录 才能发表评论!

加载中……
