配置 containerd 镜像仓库完全攻略

Linux RancherLabs 2223次浏览 0个评论

作者简介

王海龙,Rancher中国社区技术经理,负责Rancher中国技术社区的维护和运营。拥有6年的云计算领域经验,经历了OpenStack到Kubernetes的技术变革,无论底层操作系统Linux,还是虚拟化KVM或是Docker容器技术都有丰富的运维和实践经验。

前 言

Kubernetes 在 Changelog 中宣布自 Kubernetes 1.20 之后将弃用 Docker 作为容器运行时之后,containerd成为下一个容器运行时的热门选项。虽然 containerd 很早就已经是 Docker 的一部分,但是纯粹使用 containerd 还是给大家带来了诸多困扰,本文将介绍如何使用 containerd 配置镜像仓库和加速器。

本文将以K3s为例对containerd进行配置,如果您的环境未使用 K3s 而是使用的 Kubernetes,你也可以参考本文来配置 containerd 的镜像仓库,因为 containerd 的配置是通用的。

关于 K3s 和 containerd

K3s 是一个轻量级 Kubernetes 发行版,二进制大小小于100MB,所需内存不到Kubernetes的一半。K3s 为了降低资源消耗,将默认的 runtime 修改为 containerd,同时也内置了 Kubernetes CLI 工具 crictl和ctr。

K3s 默认的 containerd 配置文件目录为/var/lib/rancher/k3s/agent/etc/containerd/config.toml,但直接操作 containerd 的配置文件去设置镜像仓库或加速器相比于操作 docker 要复杂许多。K3s 为了简化配置 containerd 镜像仓库的复杂度,K3s 会在启动时检查/etc/rancher/k3s/中是否存在 registries.yaml 文件,如果存在该文件,就会根据 registries.yaml 的内容转换为 containerd 的配置并存储到/var/lib/rancher/k3s/agent/etc/containerd/config.toml,从而降低了配置 containerd 镜像仓库的复杂度。

使用 K3s 配置私有镜像仓库

K3s 镜像仓库配置文件由两大部分组成:mirrorsconfigs:

  • Mirrors 是一个用于定义专用镜像仓库的名称和 endpoint 的指令

  • Configs 部分定义了每个 mirror 的 TLS 和证书配置。对于每个 mirror,你可以定义auth和/或tls

containerd 使用了类似 K8S 中 svc 与 endpoint 的概念,svc 可以理解为访问名称,这个名称会解析到对应的 endpoint 上。也可以理解 mirror 配置就是一个反向代理,它把客户端的请求代理到 endpoint 配置的后端镜像仓库。mirror 名称可以随意填写,但是必须符合IP或域名的定义规则。并且可以配置多个 endpoint,默认解析到第一个 endpoint,如果第一个 endpoint 没有返回数据,则自动切换到第二个 endpoint,以此类推。

比如以下配置示例:

mirrors:
  "172.31.6.200:5000":
    endpoint:
      - "http://172.31.6.200:5000"
  "rancher.ksd.top:5000":
    endpoint:
      - "http://172.31.6.200:5000"
  "docker.io":
    endpoint:
      - "https://fogjl973.mirror.aliyuncs.com"
      - "https://registry-1.docker.io"

可以通过 crictl pull 172.31.6.200:5000/library/alpinecrictl pull rancher.ksd.top:5000/library/alpine获取到镜像,但镜像都是从同一个仓库获取到的。

root@rancher-server:/etc/rancher/k3s# systemctl restart k3s.service
root@rancher-server:/etc/rancher/k3s# crictl pull 172.31.6.200:5000/library/alpine
Image is up to date for sha256:a24bb4013296f61e89ba57005a7b3e52274d8edd3ae2077d04395f806b63d83e
root@rancher-server:/etc/rancher/k3s# crictl pull rancher.ksd.top:5000/library/alpine
Image is up to date for sha256:a24bb4013296f61e89ba57005a7b3e52274d8edd3ae2077d04395f806b63d83e
root@rancher-server:/etc/rancher/k3s#

非安全(http)私有仓库配置

配置非安全(http)私有仓库,只需要在 endpoint 中指定 http 协议头的地址即可。

在没有 TLS 通信的情况下,需要为 endpoints 指定http:// ,否则将默认为 https。

无认证

如果你使用的是非安全(http)私有仓库,那么可以通过下面的参数来配置 K3s 连接私有仓库:

root@ip-172-31-13-117:~# cat >> /etc/rancher/k3s/registries.yaml <<EOF
mirrors:
  "172.31.6.200:5000":
    endpoint:
      - "http://172.31.6.200:5000"
EOF
systemctl restart k3s

然后可以通过 crictl 去 pull 镜像:

root@ip-172-31-13-117:~# crictl pull 172.31.6.200:5000/my-ubuntu
Image is up to date for sha256:9499db7817713c4d10240ca9f5386b605ecff7975179f5a46e7ffd59fff462ee

接下来,在看一下 containerd 的配置,可以看到文件末尾追加了如下配置:

root@ip-172-31-13-117:~# cat /var/lib/rancher/k3s/agent/etc/containerd/config.toml
[plugins.cri.registry.mirrors]

[plugins.cri.registry.mirrors."172.31.6.200:5000"]
  endpoint = ["http://172.31.6.200:5000"]

[plugins.cri.registry.mirrors."rancher.ksd.top:5000"]
  endpoint = ["http://172.31.6.200:5000"]

有认证

如果你的非安全(http)私有仓库带有认证,那么可以通过下面的参数来配置 k3s 连接私有仓库:

mirrors:
  "35.182.134.80":
    endpoint:
      - "http://35.182.134.80"
configs:
  "35.182.134.80":
    auth:
      username: admin # this is the registry username
      password: Harbor12345 # this is the registry password
EOF
systemctl restart k3s

通过 crictl 去 pull 镜像:

root@ip-172-31-13-117:~# crictl pull 35.182.134.80/ksd/ubuntu:16.04
Image is up to date for sha256:9499db7817713c4d10240ca9f5386b605ecff7975179f5a46e7ffd59fff462ee

Containerd 配置文件末尾追加了如下配置:

[plugins.cri.registry.mirrors]

[plugins.cri.registry.mirrors."35.182.134.80"]
  endpoint = ["http://35.182.134.80"]

[plugins.cri.registry.configs."35.182.134.80".auth]
  username = "admin"
  password = "Harbor12345"

安全(https)私有仓库配置

以下示例均启用了认证,所以每个示例都配置了configs.auth,如果实际环境未配置认证,删除configs.auth配置即可。

使用授信 ssl 证书

与非安全(http)私有仓库配置类似,只需要配置 endpoint 对应的仓库地址为 https 即可。

root@ip-172-31-13-117:~# cat >> /etc/rancher/k3s/registries.yaml <<EOF
mirrors:
  "harbor.kingsd.top":
    endpoint:
      - "https://harbor.kingsd.top"
configs:
  "harbor.kingsd.top":
    auth:
      username: admin # this is the registry username
      password: Harbor12345 # this is the registry password
EOF
systemctl restart k3s

通过 crictl 去 pull 镜像:

root@ip-172-31-13-117:~# crictl pull harbor.kingsd.top/ksd/ubuntu:16.04
Image is up to date for sha256:9499db7817713c4d10240ca9f5386b605ecff7975179f5a46e7ffd59fff462ee

Containerd 配置文件末尾追加了如下配置:

root@ip-172-31-13-117:~# cat /var/lib/rancher/k3s/agent/etc/containerd/config.toml
[plugins.cri.registry.mirrors]

[plugins.cri.registry.mirrors."harbor.kingsd.top"]
  endpoint = ["https://harbor.kingsd.top"]

[plugins.cri.registry.configs."harbor.kingsd.top".auth]
  username = "admin"
  password = "Harbor12345"

使用自签 ssl 证书

如果后端仓库使用的是自签名的 ssl 证书,那么需要配置 CA 证书 用于 ssl 证书的校验。

mirrors:
  "harbor-ksd.kingsd.top":
    endpoint:
      - "https://harbor-ksd.kingsd.top"
configs:
  "harbor-ksd.kingsd.top":
    auth:
      username: admin # this is the registry username
      password: Harbor12345 # this is the registry password
    tls:
      ca_file: /opt/certs/ca.crt
EOF
systemctl restart k3s

通过 crictl 去 pull 镜像:

root@ip-172-31-13-117:~# crictl pull harbor-ksd.kingsd.top/ksd/ubuntu:16.04
Image is up to date for sha256:9499db7817713c4d10240ca9f5386b605ecff7975179f5a46e7ffd59fff462ee

Containerd 配置文件末尾追加了如下配置:

root@ip-172-31-13-117:~# cat /var/lib/rancher/k3s/agent/etc/containerd/config.toml
[plugins.cri.registry.mirrors]

[plugins.cri.registry.mirrors."harbor-ksd.kingsd.top"]
  endpoint = ["https://harbor-ksd.kingsd.top"]

[plugins.cri.registry.configs."harbor-ksd.kingsd.top".auth]
  username = "admin"
  password = "Harbor12345"

[plugins.cri.registry.configs."harbor-ksd.kingsd.top".tls]
  ca_file = "/opt/certs/ca.crt"

ssl 双向认证

如果镜像仓库配置了双向认证,那么需要为 containerd 配置 ssl 证书用于 镜像仓库对 containerd 做认证。

root@ip-172-31-13-117:~# cat >> /etc/rancher/k3s/registries.yaml <<EOF
mirrors:
  "harbor-ksd.kingsd.top":
    endpoint:
      - "https://harbor-ksd.kingsd.top"
configs:
  "harbor-ksd.kingsd.top":
    auth:
      username: admin # this is the registry username
      password: Harbor12345 # this is the registry password
    tls:
      ca_file: /opt/certs/ca.crt # path to the ca file used in the registry
      cert_file: /opt/certs/harbor-ksd.kingsd.top.cert # path to the cert file used in the registry
      key_file: /opt/certs/harbor-ksd.kingsd.top.key # path to the key file used in the registry
EOF
systemctl restart k3s

通过 crictl 去 pull 镜像:

root@ip-172-31-13-117:~# crictl pull harbor-ksd.kingsd.top/ksd/ubuntu:16.04
Image is up to date for sha256:9499db7817713c4d10240ca9f5386b605ecff7975179f5a46e7ffd59fff462ee

Containerd 配置文件末尾追加了如下配置:

[plugins.cri.registry.mirrors]

[plugins.cri.registry.mirrors."harbor-ksd.kingsd.top"]
  endpoint = ["https://harbor-ksd.kingsd.top"]

[plugins.cri.registry.configs."harbor-ksd.kingsd.top".auth]
  username = "admin"
  password = "Harbor12345"

[plugins.cri.registry.configs."harbor-ksd.kingsd.top".tls]
  ca_file = "/opt/certs/ca.crt"
  cert_file = "/opt/certs/harbor-ksd.kingsd.top.cert"
  key_file = "/opt/certs/harbor-ksd.kingsd.top.key"

加速器配置

Containerd 与 docker 都有默认仓库,均为 docker.io 。如果配置中未指定 mirror 为 docker.io,containerd 后会自动加载 docker.io 配置。与 docker 不同的是,containerd 可以修改 docker.io 对应的 endpoint(默认为 https://registry-1.docker.io ) ,而 docker 无法修改。

Docker 中可以通过 registry-mirrors 设置镜像加速地址。如果 pull 的镜像不带仓库地址(项目名+镜像名:tag),则会从默认镜像仓库去拉取镜像。如果配置了镜像加速地址,会先访问镜像加速仓库,如果没有返回数据,再访问默认的镜像仓库。

Containerd 目前没有直接配置镜像加速的功能,但 containerd 中可以修改 docker.io 对应的 endpoint,所以可以通过修改 endpoint 来实现镜像加速下载。因为 endpoint 是轮询访问,所以可以给 docker.io 配置多个仓库地址来实现 加速地址+默认仓库地址。如下配置示例:

mirrors:
  "docker.io":
    endpoint:
      - "https://fogjl973.mirror.aliyuncs.com"
      - "https://registry-1.docker.io"
EOF

systemctl restart k3s

Containerd 配置文件末尾追加了如下配置:

root@ip-172-31-13-117:~# cat /var/lib/rancher/k3s/agent/etc/containerd/config.toml
[plugins.cri.registry.mirrors]

[plugins.cri.registry.mirrors."docker.io"]
  endpoint = ["https://fogjl973.mirror.aliyuncs.com", "https://registry-1.docker.io"]

完整配置示例

  "192.168.50.119":
    endpoint:
      - "http://192.168.50.119"
  "docker.io":
    endpoint:
      - "https://fogjl973.mirror.aliyuncs.com"
      - "https://registry-1.docker.io"
configs:
  "192.168.50.119":
    auth:
      username: '' # this is the registry username
      password: '' # this is the registry password
    tls:
      cert_file: '' # path to the cert file used in the registry
      key_file: '' # path to the key file used in the registry
      ca_file: '' # path to the ca file used in the registry
  "docker.io":
    auth:
      username: '' # this is the registry username
      password: '' # this is the registry password
    tls:
      cert_file: '' # path to the cert file used in the registry
      key_file: '' # path to the key file used in the registry
      ca_file: '' # path to the ca file used in the registry

参考链接

K3s私有镜像仓库配置:

https://docs.rancher.cn/docs/k3s/installation/private-registry/_index

Containerd配置镜像仓库:

https://github.com/containerd/cri/blob/master/docs/registry.md
