主要是利用套接字,来和远程主机的逐个端口进行连接,如果连接上说明该端口是开放的,否则是关闭的。当然现在各种安全技术发展迅速,使得这种方法扫描的端口可能不太准确,但是总得从最基本的学起吧~~
实现起来也不难,关键是看执行效率如何,如果使用传统的逐个端口扫描,效率很低,即使是扫描本机,平均每个端口也需要1秒左右。提高效率的方法有很多如多线程、异步扫描。我采用的是异步扫描方式,其实这种方式也是一种多线程的方式,只是线程是交由系统创建的。
代码转自:http://blog.csdn.net/xiaohui_hubei/
using System; using System.Net; using System.Net.Sockets; using System.Collections; namespace PortScan { class Program { // code from http://www.75271.com/codes/ static void Main(string[] args) { IPAddress ip; int startPort, endPort; if (GetPortRange(args, out ip, out startPort, out endPort) == true) //提取命令行参数 { Scan(ip, startPort, endPort); //端口扫描 Console.ReadKey(); } } #region 从命令行参数 中提取端口 + static bool GetPortRange(string[] args, out int startPort, out int endPort) /// <summary> /// 从命令行参数 中提取端口 /// </summary> /// <param name="args">命令行参数</param> /// <param name="ip">输出 IP地址</param> /// <param name="startPort">输出 起始端口号</param> /// <param name="endPort">输出 终止端口号</param> /// <returns>提取成功返回true,否则返回false</returns> private static bool GetPortRange(string[] args,out IPAddress ip, out int startPort, out int endPort) { ip = null; startPort = endPort = 0; //帮助 命令 if (args.Length != 0 && (args[0] == "/?" || args[0] == "/help")) { Console.WriteLine("Scan port from startPort to endPort of the host specified by the IPAddress."); Console.WriteLine("Command Format:"); Console.WriteLine("PortScan IPAddress startPort endPort"); Console.WriteLine("For example:"); Console.WriteLine("PortScan 127.0.0.1 1 1024"); return false; } if (args.Length == 3) { //解析端口号成功 if (IPAddress.TryParse(args[0],out ip) && int.TryParse(args[1], out startPort) && int.TryParse(args[2], out endPort)) { return true; } else { Console.WriteLine("参数格式不正确!"); return false; } } else { Console.WriteLine("参数数目不正确!"); return false; } } #endregion /// <summary> /// 端口 扫描 /// </summary> /// <param name="ip">扫描的 IP地址</param> /// <param name="startPort">起始端口号</param> /// <param name="endPort">终止端口号</param> static void Scan(IPAddress ip, int startPort, int endPort) { Random rand = new Random((int)DateTime.Now.Ticks); Console.WriteLine("Begin Scan..."); for (int port = startPort; port < endPort; port++) { Socket scanSocket = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.IP); //寻找一个未使用的端口进行绑定 do { try { scanSocket.Bind(new IPEndPoint(IPAddress.Any, rand.Next(65535))); break; } catch { //绑定失败 } } while (true); try { scanSocket.BeginConnect(new IPEndPoint(ip, port), ScanCallBack, new ArrayList() { scanSocket, port}); } catch { // Console.WriteLine("port {0,5}\tClosed.\n{1}", port, ex.Message); continue; } } Console.WriteLine("Port Scan Completed!"); } /// <summary> /// BeginConnect的回调函数 /// </summary> /// <param name="result">异步Connect的结果</param> static void ScanCallBack(IAsyncResult result) { //解析 回调函数输入 参数 ArrayList arrList = (ArrayList)result.AsyncState; Socket scanSocket = (Socket)arrList[0]; int port = (int)arrList[1]; //判断端口是否开放 if (result.IsCompleted && scanSocket.Connected) { Console.WriteLine("port {0,5}\tOpen.", port); } else { //Console.WriteLine("port {0,5}\tClosed.", port); } //关闭套接字 scanSocket.Close(); } } }
