通过无人机机载摄像头构建建筑物 3D 模型

《一》实现步骤： （1）启动 Gazebo 模拟器； （2）起飞无人机并开始录制一个 rosbag; （3）控制无人机围绕建筑物绕圆周飞行一圈； （4）停止 rosbag 录制并使用提供的脚本提取图片； （5）使用提供的网站构建模型   前期准备： （1）更新GAAS 1）改变路径到GAAS 所在的路径或者在GAAS 打开终端

cd /home/yyl/catkin_ws/GAAS

  2）更新

git pull origin master

  3）将 Gazebo 仿真用到的文件拷贝到 PX4 文件所在目录中

cp -r /home/yyl/catkin_ws/GAAS/simulator/launch/* ~/catkin_ws/src/Firmware/launch/
cp -r /home/yyl/catkin_ws/GAAS/simulator/models/* ~/catkin_ws/src/Firmware/Tools/sitl_gazebo/models/
cp -r /home/yyl/catkin_ws/GAAS/simulator/worlds/* ~/catkin_ws/src/Firmware/Tools/sitl_gazebo/worlds/
cp -r /home/yyl/catkin_ws/GAAS/simulator/posix-config/* ~/catkin_ws/src/Firmware/posix-configs/SITL/init/ekf2/

    《二》启动仿真

roslaunch px4 sfm.launch


  检查MAVROS 的连接情况:

rostopic echo /mavros/state


  通过 Rviz 来查看发布出来的摄像头图片:

rviz

  选择 “Add”->“by topic”->”/gi/simulation/left/image_raw“ 订阅并存储左目摄像头的信息:

rosbag record /gi/simulation/left/image_raw -O sfm.bag

  起飞无人机:

python  /home/yyl/catkin_ws/GAAS/demo/tutorial_2/2_Struction_from_Motion/px4_mavros_run.py

  脚本控制无人机围绕圆形飞行:

python /home/yyl/catkin_ws/GAAS/demo/tutorial_2/fly_circle.py

  将 rosbag 中的图片信息提取出来

 python /home/yyl/catkin_ws/GAAS/demo/tutorial_2/2_Struction_from_Motion/bag2image.py --bag /home/yyl/sfm.bag  --output_path /home/yyl/picture --image_topic /gi/simulation/left/image_raw

  选择图片并上传

aviation.giai.tech

即可构建模型 具体教程见：https://gaas.gitbook.io/guide/software-realization-build-your-own-autonomous-drone/wu-ren-ji-zi-dong-jia-shi-xi-lie-tong-guo-wu-ren-ji-ji-zai-she-xiang-tou-gou-jian-jian-zhu-wu-3d-mo 我实现的效果：
