MyBatis 动态SQL

JAVA相关 supingemail 2492次浏览 0个评论

.


MyBatis 令人喜欢的一大特性就是动态 SQL。在使用 JDBC 的过程中, 根据条件进行 SQL 的拼接是很麻烦且很容易出错的。MyBatis 动态 SQL 的出现, 解决了这个麻烦。

MyBatis通过 OGNL 来进行动态 SQL 的使用的。目前, 动态 SQL 支持以下几种标签:



1 数据准备

为了后面的演示, 创建了一个 Maven 项目 mybatis-dynamic, 创建了对应的数据库和表

DROP TABLE IF EXISTS `student`;

CREATE TABLE `student` (
  `student_id` int(10) unsigned NOT NULL AUTO_INCREMENT COMMENT '编号',
  `name` varchar(20) DEFAULT NULL COMMENT '姓名',
  `phone` varchar(20) DEFAULT NULL COMMENT '电话',
  `email` varchar(50) DEFAULT NULL COMMENT '邮箱',
  `sex` tinyint(4) DEFAULT NULL COMMENT '性别',
  `locked` tinyint(4) DEFAULT NULL COMMENT '状态(0:正常,1:锁定)',
  `gmt_created` datetime DEFAULT CURRENT_TIMESTAMP COMMENT '存入数据库的时间',
  `gmt_modified` datetime DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP COMMENT '修改的时间',
  `delete` int(11) DEFAULT NULL,
  PRIMARY KEY (`student_id`)
) ENGINE=InnoDB AUTO_INCREMENT=7 DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci COMMENT='学生表';

对应的项目结构





2 if 标签

if 标签是我们最常使用的。在查询、删除、更新的时候很可能会使用到。必须结合 test 属性联合使用。

2.1 在 WHERE 条件中使用 if 标签

这是常见的一种现象, 我们在进行按条件查询的时候, 可能会有多种情况。



2.1.1 查询条件

根据输入的学生信息进行条件检索

  • 当只输入用户名时, 使用用户名进行模糊检索;

  • 当只输入性别时, 使用性别进行完全匹配

  • 当用户名和性别都存在时, 用这两个条件进行查询匹配查询

2.1.2 动态 SQL

接口函数

    /**
     * 根据输入的学生信息进行条件检索
     * 1. 当只输入用户名时, 使用用户名进行模糊检索;
     * 2. 当只输入邮箱时, 使用性别进行完全匹配
     * 3. 当用户名和性别都存在时, 用这两个条件进行查询匹配的用
     * @param student
     * @return
     */
        List<Student> selectByStudentSelective(Student student);

对应的动态 SQL

  <select id="selectByStudentSelective" resultMap="BaseResultMap" parameterType="com.homejim.mybatis.entity.Student">
    select
    <include refid="Base_Column_List" />
    from student
    where 1=1
    <if test="name != null and name !=''">
      and name like concat('%', #{name}, '%')
    </if>
    <if test="sex != null">
      and sex=#{sex}
    </if>
  </select>

在此 SQL 语句中, where 1=1 是多条件拼接时的小技巧, 后面的条件查询就可以都用 and 了。

同时, 我们添加了 if 标签来处理动态 SQL

    <if test="name != null and name !=''">
      and name like concat('%', #{name}, '%')
    </if>
    <if test="sex != null">
      and sex=#{sex}
    </if>

此 if 标签的 test 属性值是一个符合 OGNL 的表达式, 表达式可以是 true 或 false。如果表达式返回的是数值, 则0为 false, 非 0 为 true;

2.1.3 测试

     @Test
    public void selectByStudent() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        Student search = new Student();
        search.setName("明");

        System.out.println("只有名字时的查询");
        List<Student> studentsByName = studentMapper.selectByStudentSelective(search);
        for (int i = 0; i < studentsByName.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(studentsByName.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        search.setName(null);
        search.setSex((byte) 1);
        System.out.println("只有性别时的查询");
        List<Student> studentsBySex = studentMapper.selectByStudentSelective(search);
        for (int i = 0; i < studentsBySex.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(studentsBySex.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        System.out.println("姓名和性别同时存在的查询");
        search.setName("明");
        List<Student> studentsByNameAndSex = studentMapper.selectByStudentSelective(search);
        for (int i = 0; i < studentsByNameAndSex.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(studentsByNameAndSex.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        sqlSession.commit();
        sqlSession.close();
    }

只有名字时的查询, 发送的语句和结果



查询的条件只发送了

where 1=1 and name like concat('%', ?, '%')

只有性别时的查询, 发送的语句和结果



查询的条件只发送了

where 1=1 and sex=?

姓名和性别同时存在的查询, 发送的语句和结果



查询条件

where 1=1 and name like concat('%', ?, '%') and sex=?

2.2 在 UPDATE 更新列中使用 if 标签

有时候我们不希望更新所有的字段, 只更新有变化的字段。



2.2.1 更新条件

只更新有变化的字段, 空值不更新。

2.2.1 动态 SQL

接口方法

    /**
     * 更新非空属性
     */
    int updateByPrimaryKeySelective(Student record);

对应的 SQL

  <update id="updateByPrimaryKeySelective" parameterType="com.homejim.mybatis.entity.Student">
    update student
    <set>
      <if test="name != null">
        `name` = #{name,jdbcType=VARCHAR},
      </if>
      <if test="phone != null">
        phone = #{phone,jdbcType=VARCHAR},
      </if>
      <if test="email != null">
        email = #{email,jdbcType=VARCHAR},
      </if>
      <if test="sex != null">
        sex = #{sex,jdbcType=TINYINT},
      </if>
      <if test="locked != null">
        locked = #{locked,jdbcType=TINYINT},
      </if>
      <if test="gmtCreated != null">
        gmt_created = #{gmtCreated,jdbcType=TIMESTAMP},
      </if>
      <if test="gmtModified != null">
        gmt_modified = #{gmtModified,jdbcType=TIMESTAMP},
      </if>
    </set>
    where student_id = #{studentId,jdbcType=INTEGER}

2.2.3 测试

    @Test
    public void updateByStudentSelective() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        Student student = new Student();
        student.setStudentId(1);
        student.setName("明明");
        student.setPhone("13838438888");
        System.out.println(studentMapper.updateByPrimaryKeySelective(student));

        sqlSession.commit();
        sqlSession.close();
    }

结果如下



2.3 在 INSERT 动态插入中使用 if 标签

我们插入数据库中的一条记录, 不是每一个字段都有值的, 而是动态变化的。在这时候使用 if 标签, 可帮我们解决这个问题。

2.3.1 插入条件

只有非空属性才插入。

2.3.2 动态SQL

接口方法

    /**
     * 非空字段才进行插入
     */
    int insertSelective(Student record);

对应的SQL

<insert id="insertSelective" parameterType="com.homejim.mybatis.entity.Student">
    insert into student
    <trim prefix="(" suffix=")" suffixOverrides=",">
      <if test="studentId != null">
        student_id,
      </if>
      <if test="name != null">
        `name`,
      </if>
      <if test="phone != null">
        phone,
      </if>
      <if test="email != null">
        email,
      </if>
      <if test="sex != null">
        sex,
      </if>
      <if test="locked != null">
        locked,
      </if>
      <if test="gmtCreated != null">
        gmt_created,
      </if>
      <if test="gmtModified != null">
        gmt_modified,
      </if>
    </trim>
    <trim prefix="values (" suffix=")" suffixOverrides=",">
      <if test="studentId != null">
        #{studentId,jdbcType=INTEGER},
      </if>
      <if test="name != null">
        #{name,jdbcType=VARCHAR},
      </if>
      <if test="phone != null">
        #{phone,jdbcType=VARCHAR},
      </if>
      <if test="email != null">
        #{email,jdbcType=VARCHAR},
      </if>
      <if test="sex != null">
        #{sex,jdbcType=TINYINT},
      </if>
      <if test="locked != null">
        #{locked,jdbcType=TINYINT},
      </if>
      <if test="gmtCreated != null">
        #{gmtCreated,jdbcType=TIMESTAMP},
      </if>
      <if test="gmtModified != null">
        #{gmtModified,jdbcType=TIMESTAMP},
      </if>
    </trim>
  </insert>

这个 SQL 大家应该很熟悉, 毕竟是自动生成的。

2.3.3 测试

    @Test
    public void insertByStudentSelective() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        Student student = new Student();
        student.setName("小飞机");
        student.setPhone("13838438899");
        student.setEmail("xiaofeiji@qq.com");
        student.setLocked((byte) 0);

        System.out.println(studentMapper.insertSelective(student));

        sqlSession.commit();
        sqlSession.close();
    }

对应的结果



SQL 中, 只有非空的字段才进行了插入。

3 choose 标签

choose when otherwise 标签可以帮我们实现 if else 的逻辑。一个 choose 标签至少有一个 when, 最多一个otherwise。

下面是一个查询的例子。

3.1 查询条件

假设 name 具有唯一性, 查询一个学生

  • 当 studen_id 有值时, 使用 studen_id 进行查询;

  • 当 studen_id 没有值时, 使用 name 进行查询;

  • 否则返回空

3.2 动态SQL

接口方法

    /**
     * - 当 studen_id 有值时, 使用 studen_id 进行查询;
     * - 当 studen_id 没有值时, 使用 name 进行查询;
     * - 否则返回空
     */
    Student selectByIdOrName(Student record);

对应的SQL

  <select id="selectByIdOrName" resultMap="BaseResultMap" parameterType="com.homejim.mybatis.entity.Student">
    select
    <include refid="Base_Column_List" />
    from student
    where 1=1
    <choose>
      <when test="studentId != null">
        and student_id=#{studentId}
      </when>
      <when test="name != null and name != ''">
        and name=#{name}
      </when>
      <otherwise>
        and 1=2
      </otherwise>
    </choose>
  </select>

3.3 测试

 @Test
    public void selectByIdOrName() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        Student student = new Student();
        student.setName("小飞机");
        student.setStudentId(1);

        Student studentById = studentMapper.selectByIdOrName(student);
        System.out.println("有 ID 则根据 ID 获取");
        System.out.println(ToStringBuilder.reflectionToString(studentById, ToStringStyle.MULTI_LINE_STYLE));

        student.setStudentId(null);
        Student studentByName = studentMapper.selectByIdOrName(student);
        System.out.println("没有 ID 则根据 name 获取");
        System.out.println(ToStringBuilder.reflectionToString(studentByName, ToStringStyle.MULTI_LINE_STYLE));

        student.setName(null);
        Student studentNull = studentMapper.selectByIdOrName(student);
        System.out.println("没有 ID 和 name, 返回 null");
        Assert.assertNull(studentNull);

        sqlSession.commit();
        sqlSession.close();
    }

有 ID 则根据 ID 获取, 结果



没有 ID 则根据 name 获取



没有 ID 和 name, 返回 null



4 trim(set、where)

这三个其实解决的是类似的问题。如我们在写前面的[在 WHERE 条件中使用 if 标签] SQL 的时候, where 1=1 这个条件我们是不希望存在的。

4.1 where

4.1.1 查询条件

根据输入的学生信息进行条件检索。

  • 当只输入用户名时, 使用用户名进行模糊检索;

  • 当只输入性别时, 使用性别进行完全匹配

  • 当用户名和性别都存在时, 用这两个条件进行查询匹配查询

不使用 where 1=1。

4.1.2 动态 SQL

很显然, 我们要解决这几个问题

当条件都不满足时:此时 SQL 中应该要不能有 where , 否则导致出错
当 if 有条件满足时:SQL 中需要有 where, 且第一个成立的 if 标签下的 and | or 等要去掉
这时候, 我们可以使用 where 标签。

接口方法

    /**
     * 根据输入的学生信息进行条件检索
     * 1. 当只输入用户名时, 使用用户名进行模糊检索;
     * 2. 当只输入邮箱时, 使用性别进行完全匹配
     * 3. 当用户名和性别都存在时, 用这两个条件进行查询匹配的用
     */
    List<Student> selectByStudentSelectiveWhereTag(Student student);

对应的 SQL

  <select id="selectByStudentSelectiveWhereTag" resultMap="BaseResultMap" parameterType="com.homejim.mybatis.entity.Student">
    select
    <include refid="Base_Column_List" />
    from student
   <where>
    <if test="name != null and name !=''">
      and name like concat('%', #{name}, '%')
    </if>
    <if test="sex != null">
      and sex=#{sex}
    </if>
   </where>
  </select>

4.1.3 测试

    @Test
    public void selectByStudentWhereTag() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        Student search = new Student();
        search.setName("明");

        System.out.println("只有名字时的查询");
        List<Student> studentsByName = studentMapper.selectByStudentSelectiveWhereTag(search);
        for (int i = 0; i < studentsByName.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(studentsByName.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        search.setSex((byte) 1);
        System.out.println("姓名和性别同时存在的查询");
        List<Student> studentsBySex = studentMapper.selectByStudentSelectiveWhereTag(search);
        for (int i = 0; i < studentsBySex.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(studentsBySex.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        System.out.println("姓名和性别都不存在时查询");
        search.setName(null);
        search.setSex(null);
        List<Student> studentsByNameAndSex = studentMapper.selectByStudentSelectiveWhereTag(search);
        for (int i = 0; i < studentsByNameAndSex.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(studentsByNameAndSex.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        sqlSession.commit();
        sqlSession.close();
    }

只有名字时的查询, 有 where



姓名和性别同时存在的查询, 有 where



姓名和性别都不存在时查询, 此时, where 不会再出现了。



4.2 set

set 标签也类似, 在 [2.2 在 UPDATE 更新列中使用 if 标签] 中, 如果我们的方法 updateByPrimaryKeySelective 没有使用

4.3 trim

set 和 where 其实都是 trim 标签的一种类型, 该两种功能都可以使用 trim 标签进行实现。

4.3.1 trim 来表示 where

如以上的 where 标签, 我们也可以写成

<trim prefix="where" prefixOverrides="AND |OR">
</trim>

表示当 trim 中含有内容时, 添加 where, 且第一个为 and 或 or 时, 会将其去掉。而如果没有内容, 则不添加 where。

4.3.2 trim 来表示 set

相应的, set 标签可以如下表示

<trim prefix="SET" suffixOverrides=",">
</trim>

表示当 trim 中含有内容时, 添加 set, 且最后的内容为 , 时, 会将其去掉。而没有内容, 不添加 set

4.3.3 trim 的几个属性

  • prefix: 当 trim 元素包含有内容时, 增加 prefix 所指定的前缀

  • prefixOverrides: 当 trim 元素包含有内容时, 去除 prefixOverrides 指定的 前缀

  • suffix: 当 trim 元素包含有内容时, 增加 suffix 所指定的后缀

  • suffixOverrides:当 trim 元素包含有内容时, 去除 suffixOverrides 指定的后缀

5 foreach 标签

foreach 标签可以对数组, Map 或实现 Iterable 接口。

foreach 中有以下几个属性:

  • collection: 必填, 集合/数组/Map的名称.

  • item: 变量名。即从迭代的对象中取出的每一个值

  • index: 索引的属性名。当迭代的对象为 Map 时, 该值为 Map 中的 Key.

  • open: 循环开头的字符串

  • close: 循环结束的字符串

  • separator: 每次循环的分隔符

其他的比较好理解, collection 中的值应该怎么设定呢?

跟接口方法中的参数相关。

1. 只有一个数组参数或集合参数

默认情况:集合collection=list, 数组是collection=array

推荐:使用 @Param 来指定参数的名称, 如我们在参数前@Param(“ids”), 则就填写 collection=ids

2. 多参数

多参数请使用 @Param 来指定, 否则SQL中会很不方便

3. 参数是Map

指定为 Map 中的对应的 Key 即可。其实上面的 @Param 最后也是转化为 Map 的。

4. 参数是对象

使用属性.属性即可。

5.1 在 where 中使用 foreach

在 where条件中使用, 如按id集合查询, 按id集合删除等。

5.1.1 查询条件

我们希望查询用户 id 集合中的所有用户信息。

5.1.2 动态 SQL

函数接口

    /**
     * 获取 id 集合中的用户信息
     * @param ids
     * @return
     */
    List<Student> selectByStudentIdList(List<Integer> ids);

对应 SQL

  <select id="selectByStudentIdList" resultMap="BaseResultMap">
    select
    <include refid="Base_Column_List" />
    from student
    where student_id in
    <foreach collection="list" item="id" open="(" close=")" separator="," index="i">
      #{id}
    </foreach>
  </select>

5.1.3 测试

    @Test
    public void selectByStudentIdList() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        List<Integer> ids = new LinkedList<>();
        ids.add(1);
        ids.add(3);

        List<Student> students = studentMapper.selectByStudentIdList(ids);
        for (int i = 0; i < students.size(); i++) {
            System.out.println(ToStringBuilder.reflectionToString(students.get(i), ToStringStyle.MULTI_LINE_STYLE));
        }

        sqlSession.commit();
        sqlSession.close();
    }

结果



5.2 foreach 实现批量插入

可以通过foreach来实现批量插入。

5.2.1 动态SQL

接口方法

    /**
     * 批量插入学生
     */
    int insertList(List<Student> students);

对应的SQL

  <insert id="insertList">
    insert into student(name, phone, email, sex, locked)
    values
    <foreach collection="list" item="student" separator=",">
      (
      #{student.name}, #{student.phone},#{student.email},
      #{student.sex},#{student.locked}
      )
    </foreach>
  </insert>

5.2.2 测试

    @Test
    public void insertList() {
        SqlSession sqlSession = null;
        sqlSession = sqlSessionFactory.openSession();
        StudentMapper studentMapper = sqlSession.getMapper(StudentMapper.class);

        List<Student> students = new LinkedList<>();
        Student stu1 = new Student();
        stu1.setName("批量01");
        stu1.setPhone("13888888881");
        stu1.setLocked((byte) 0);
        stu1.setEmail("13888888881@138.com");
        stu1.setSex((byte) 1);
        students.add(stu1);

        Student stu2 = new Student();
        stu2.setName("批量02");
        stu2.setPhone("13888888882");
        stu2.setLocked((byte) 0);
        stu2.setEmail("13888888882@138.com");
        stu2.setSex((byte) 0);
        students.add(stu2);

        System.out.println(studentMapper.insertList(students));
        sqlSession.commit();
        sqlSession.close();
    }

结果



6 bind 标签

bind 标签是通过 OGNL 表达式去定义一个上下文的变量, 这样方便我们使用。

如在 selectByStudentSelective 方法中, 有如下

<if test="name != null and name !=''">
      and name like concat('%', #{name}, '%')
    </if>

在 MySQL 中, 该函数支持多参数, 但在 Oracle 中只支持两个参数。那么我们可以使用 bind 来让该 SQL 达到支持两个数据库的作用

<if test="name != null and name !=''">
     <bind name="nameLike" value="'%'+name+'%'"/>
     and name like #{nameLike}
</if>

更改后的查询结果如下



7 代码

使用示例:

https://github.com/homejim/mybatis-examples


开心洋葱 , 版权所有丨如未注明 , 均为原创丨未经授权请勿修改 , 转载请注明MyBatis 动态SQL
喜欢 (0)

您必须 登录 才能发表评论!

加载中……
