本篇概览
-
本文是《MyBatis初级实战》系列的第六篇,继续实践从多表获取数据;
-
回顾上一篇,咱们实战了多表关联的一对一关系,如下图所示,查找日志记录时,把对应的用户信息查出:
-
本篇要实践的是一对多关系:查询用户记录时,把该用户的所有日志记录都查出来,逻辑关系如下图:
- 在具体编码实现一对多查询时,分别使用联表和嵌套两种方式实现,每种方式都按照下图的步骤执行:
源码下载
- 如果您不想编码,可以在GitHub下载所有源码,地址和链接信息如下表所示(https://github.com/zq2599/blog_demos):
名称 | 链接 | 备注 |
---|---|---|
项目主页 | https://github.com/zq2599/blog_demos | 该项目在GitHub上的主页 |
git仓库地址(https) | https://github.com/zq2599/blog_demos.git | 该项目源码的仓库地址,https协议 |
git仓库地址(ssh) | git@github.com:zq2599/blog_demos.git | 该项目源码的仓库地址,ssh协议 |
- 这个git项目中有多个文件夹,本章的应用在mybatis文件夹下,如下图红框所示:
3. mybatis是个父工程,里面有数个子工程,本篇的源码在relatedoperation子工程中,如下图红框所示:
准备数据
- 本次实战,在名为mybatis的数据库中建立两个表(和前面几篇文章中的表结构一模一样):user和log表;
- user表记录用户信息,非常简单,只有三个字段:主键、名称、年龄
- log表记录用户行为,四个字段:主键、用户id、行为描述、行为时间
- user和log的关系如下图:
5. 建表和添加数据的语句如下:
use mybatis;
DROP TABLE IF EXISTS `user`;
CREATE TABLE `user` (
`id` int(32) NOT NULL AUTO_INCREMENT,
`name` varchar(32) NOT NULL,
`age` int(32) NOT NULL,
PRIMARY KEY (`id`)
) ENGINE=InnoDB AUTO_INCREMENT=3 DEFAULT CHARSET=utf8;
DROP TABLE IF EXISTS `log`;
CREATE TABLE `log` (
`id` int(32) NOT NULL AUTO_INCREMENT,
`user_id` int(32),
`action` varchar(255) NOT NULL,
`create_time` datetime not null,
PRIMARY KEY (`id`)
) ENGINE=InnoDB AUTO_INCREMENT=3 DEFAULT CHARSET=utf8;
INSERT INTO mybatis.user (id, name, age) VALUES (3, 'tom', 11);
INSERT INTO mybatis.log (id, user_id, action, create_time) VALUES (3, 3, 'read book', '2020-08-07 08:18:16');
INSERT INTO mybatis.log (id, user_id, action, create_time) VALUES (4, 3, 'go to the cinema', '2020-09-02 20:00:00');
INSERT INTO mybatis.log (id, user_id, action, create_time) VALUES (5, 3, 'have a meal', '2020-10-05 12:03:36');
INSERT INTO mybatis.log (id, user_id, action, create_time) VALUES (6, 3, 'have a sleep', '2020-10-06 13:00:12');
INSERT INTO mybatis.log (id, user_id, action, create_time) VALUES (7, 3, 'write', '2020-10-08 09:21:11');
关于多表关联查询的两种方式
- 多表关联查询的实现有联表和嵌套查询两种,它们的差异在Mybatis中体现在resultMap的定义上:
- 联表时,resultMap内使用collection子节点,将联表查询的结果映射到关联对象集合;
- 嵌套时,resultMap内使用association子节点,association的select属性触发一次新的查询;
- 上述两种方式都能成功得到查询结果,接下来逐一尝试;
联表查询
- 本篇继续使用上一篇中创建的子工程relatedoperation;
- 实体类UserWithLogs.java如下,可见成员变量logs是用来保存该用户所有日志的集合:
package com.bolingcavalry.relatedoperation.entity;
import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;
import lombok.Data;
import lombok.NoArgsConstructor;
import java.util.List;
@Data
@NoArgsConstructor
@ApiModel(description = "用户实体类(含行为日志集合)")
public class UserWithLogs {
@ApiModelProperty(value = "用户ID")
private Integer id;
@ApiModelProperty(value = "用户名", required = true)
private String name;
@ApiModelProperty(value = "用户地址", required = false)
private Integer age;
@ApiModelProperty(value = "行为日志", required = false)
private List<Log> logs;
}
- 保存SQL的UserMapper.xml如下,先把联表查询的SQL写出来,结果在名为
leftJoinResultMap的resultMap中处理:
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.bolingcavalry.relatedoperation.mapper.UserMapper">
<select id="leftJoinSel" parameterType="int" resultMap="leftJoinResultMap">
select
u.id as user_id,
u.name as user_name,
u.age as user_age,
l.id as log_id,
l.user_id as log_user_id,
l.action as log_action,
l.create_time as log_create_time
from mybatis.user as u
left join mybatis.log as l
on u.id = l.user_id
where u.id = #{id}
</select>
</mapper>
- leftJoinResultMap这个resultMap是一对多的关键,里面的collection将log的所有记录映射到logs集合中:
<resultMap id="leftJoinResultMap" type="UserWithLogs">
<id property="id" column="user_id"/>
<result property="name" column="user_name" jdbcType="VARCHAR"/>
<result property="age" column="user_age" jdbcType="INTEGER" />
<collection property="logs" ofType="Log">
<id property="id" column="log_id"/>
<result property="userId" column="log_user_id" jdbcType="INTEGER" />
<result property="action" column="log_action" jdbcType="VARCHAR" />
<result property="createTime" column="log_create_time" jdbcType="TIMESTAMP" />
</collection>
</resultMap>
- 接口定义UserMapper.java :
@Repository
public interface UserMapper {
UserWithLogs leftJoinSel(int id);
}
- service层:
@Service
public class UserService {
@Autowired
UserMapper userMapper;
public UserWithLogs leftJoinSel(int id) {
return userMapper.leftJoinSel(id);
}
}
- controller层的代码略多,是因为想把swagger信息做得尽量完整:
@RestController
@RequestMapping("/user")
@Api(tags = {"UserController"})
public class UserController {
@Autowired
private UserService userService;
@ApiOperation(value = "根据ID查找user记录(包含行为日志),联表查询", notes="根据ID查找user记录(包含行为日志),联表查询")
@ApiImplicitParam(name = "id", value = "用户ID", paramType = "path", required = true, dataType = "Integer")
@RequestMapping(value = "/leftjoin/{id}", method = RequestMethod.GET)
public UserWithLogs leftJoinSel(@PathVariable int id){
return userService.leftJoinSel(id);
}
}
- 最后是单元测试,在前文创建的ControllerTest.java中新建内部类User用于user表相关的单元测试,可见封装了一个私有方法queryAndCheck负责请求和验证结果,后面的嵌套查询也会用到:
@Nested
@TestMethodOrder(MethodOrderer.OrderAnnotation.class)
@DisplayName("用户服务")
class User {
/**
* 通过用户ID获取用户信息有两种方式:left join和嵌套查询,
* 从客户端来看,仅一部分path不同,因此将请求和检查封装到一个通用方法中,
* 调用方法只需要指定不同的那一段path
* @param subPath
* @throws Exception
*/
private void queryAndCheck(String subPath) throws Exception {
String queryPath = "/user/" + subPath + "/" + TEST_USER_ID;
log.info("query path [{}]", queryPath);
mvc.perform(MockMvcRequestBuilders.get(queryPath).accept(MediaType.APPLICATION_JSON))
.andExpect(status().isOk())
.andExpect(jsonPath("$.id").value(TEST_USER_ID))
.andExpect(jsonPath("$..logs.length()").value(5))
.andDo(print());
}
@Test
@DisplayName("通过用户ID获取用户信息(包含行为日志),联表查询")
@Order(1)
void leftJoinSel() throws Exception {
queryAndCheck(SEARCH_TYPE_LEFT_JOIN);
}
}
- 执行上述单元测试方法leftJoinSel,得到结果如下:
- 为了便于观察,我将上图红框中的JSON数据做了格式化,如下所示,可见log表中的五条记录都被关联出来了,作为整个user对象的一个字段:
{
"id": 3,
"name": "tom",
"age": 11,
"logs": [
{
"id": 3,
"userId": 3,
"action": "read book",
"createTime": "2020-08-07"
},
{
"id": 4,
"userId": 3,
"action": "go to the cinema",
"createTime": "2020-09-02"
},
{
"id": 5,
"userId": 3,
"action": "have a meal",
"createTime": "2020-10-05"
},
{
"id": 6,
"userId": 3,
"action": "have a sleep",
"createTime": "2020-10-06"
},
{
"id": 7,
"userId": 3,
"action": "write",
"createTime": "2020-10-08"
}
]
}
- 以上就是通过联表的方式获取一对多关联结果,接下来咱们尝试嵌套查询;
嵌套查询
- 嵌套查询的基本思路是将多次查询将结果合并,关键点还是在SQL和resultMap的配置上,先看嵌套查询的SQL,在UserMapper.xml文件中,如下,可见仅查询了user表,并未涉及log表:
<select id="nestedSel" parameterType="int" resultMap="nestedResultMap">
select
u.id as user_id,
u.name as user_name,
u.age as user_age
from mybatis.user as u
where u.id = #{id}
</select>
- 上面的SQL显示结果保存在名为nestedResultMap的resultMap中,来看这个resultMap,如下,可见实体类的logs字段对应的是一个association节点,该节点的select属性代表这是个子查询,查询条件是user_id:
<!-- association节点的select属性会触发嵌套查询-->
<resultMap id="nestedResultMap" type="UserWithLogs">
<!-- column属性中的user_id,来自前面查询时的"u.id as user_id" -->
<id property="id" column="user_id"/>
<!-- column属性中的user_name,来自前面查询时的"u.name as user_name" -->
<result property="name" column="user_name" jdbcType="VARCHAR"/>
<!-- column属性中的user_age,来自前面查询时的"u.age as user_age" -->
<result property="age" column="user_age" jdbcType="INTEGER" />
<!-- select属性,表示这里要执行嵌套查询,将user_id传给嵌套的查询 -->
<association property="logs" column="user_id" select="selectLogByUserId"></association>
</resultMap>
- 名为selectLogByUserId的SQL和resultMap如下,即查询log表:
<select id="selectLogByUserId" parameterType="int" resultMap="log">
select
l.id,
l.user_id,
l.action,
l.create_time
from mybatis.log as l
where l.user_id = #{user_id}
</select>
<resultMap id="log" type="log">
<id property="id" column="id"/>
<result column="user_id" jdbcType="INTEGER" property="userId"/>
<result column="action" jdbcType="VARCHAR" property="action"/>
<result column="create_time" jdbcType="TIMESTAMP" property="createTime"/>
<result column="user_name" jdbcType="VARCHAR" property="userName"/>
</resultMap>
- 以上就是嵌套查询的关键点了,接下来按部就班的在LogMapper、LogService、LogController中添加方法即可,下面是LogController中对应的web接口,稍后会在单元测试中调用这个接口进行验证:
@ApiOperation(value = "根据ID查找user记录(包含行为日志),嵌套查询", notes="根据ID查找user记录(包含行为日志),嵌套查询")
@ApiImplicitParam(name = "id", value = "用户ID", paramType = "path", required = true, dataType = "Integer")
@RequestMapping(value = "/nested/{id}", method = RequestMethod.GET)
public UserWithLogs nestedSel(@PathVariable int id){
return userService.nestedSel(id);
}
- 单元测试的代码很简单,调用前面封装好的queryAndCheck方法即可:
@Test
@DisplayName("通过用户ID获取用户信息(包含行为日志),嵌套查询")
@Order(2)
void nestedSel() throws Exception {
queryAndCheck(SEARCH_TYPE_NESTED);
}
- 执行单元测试的结果如下图红框所示,和前面的联表查询一样:
- 两种方式的一对多关联查询都试过了,接下来看看两者的区别;
联表和嵌套的区别
- 首先是联表查询的日志,如下,只有一次查询:
2020-10-21 20:25:05.754 INFO 15408 --- [ main] c.b.r.controller.ControllerTest : query path [/user/leftjoin/3]
2020-10-21 20:25:09.910 INFO 15408 --- [ main] com.alibaba.druid.pool.DruidDataSource : {dataSource-1} inited
2020-10-21 20:25:09.925 DEBUG 15408 --- [ main] c.b.r.mapper.UserMapper.leftJoinSel : ==> Preparing: select u.id as user_id, u.name as user_name, u.age as user_age, l.id as log_id, l.user_id as log_user_id, l.action as log_action, l.create_time as log_create_time from mybatis.user as u left join mybatis.log as l on u.id = l.user_id where u.id = ?
2020-10-21 20:25:10.066 DEBUG 15408 --- [ main] c.b.r.mapper.UserMapper.leftJoinSel : ==> Parameters: 3(Integer)
2020-10-21 20:25:10.092 DEBUG 15408 --- [ main] c.b.r.mapper.UserMapper.leftJoinSel : <== Total: 5
- 再来看看嵌套查询的日志,两次:
2020-10-21 20:37:29.648 INFO 24384 --- [ main] c.b.r.controller.ControllerTest : query path [/user/nested/3]
2020-10-21 20:37:33.867 INFO 24384 --- [ main] com.alibaba.druid.pool.DruidDataSource : {dataSource-1} inited
2020-10-21 20:37:33.880 DEBUG 24384 --- [ main] c.b.r.mapper.UserMapper.nestedSel : ==> Preparing: select u.id as user_id, u.name as user_name, u.age as user_age from mybatis.user as u where u.id = ?
2020-10-21 20:37:34.018 DEBUG 24384 --- [ main] c.b.r.mapper.UserMapper.nestedSel : ==> Parameters: 3(Integer)
2020-10-21 20:37:34.041 DEBUG 24384 --- [ main] c.b.r.m.UserMapper.selectLogByUserId : ====> Preparing: select l.id, l.user_id, l.action, l.create_time from mybatis.log as l where l.user_id = ?
2020-10-21 20:37:34.043 DEBUG 24384 --- [ main] c.b.r.m.UserMapper.selectLogByUserId : ====> Parameters: 3(Integer)
2020-10-21 20:37:34.046 DEBUG 24384 --- [ main] c.b.r.m.UserMapper.selectLogByUserId : <==== Total: 5
2020-10-21 20:37:34.047 DEBUG 24384 --- [ main] c.b.r.mapper.UserMapper.nestedSel : <== Total: 1
- 至此,MyBatis常用的多表关联查询实战就完成了,希望能给您一些参考,接下来的文章,咱们继续体验MyBatis带给我们的各种特性。
