引入 Gateway 网关,这些坑一定要学会避开!!!

其他 开心洋葱 1749次浏览 0个评论

Spring cloud gateway是替代zuul的网关产品,基于Spring 5、Spring boot 2.0以上、Reactor, 提供任意的路由匹配和断言、过滤功能。上一篇文章谈了一下Gateway网关使用不规范,同事加班泪两行~,这篇文章将会侧重于其他的几个需要注意的地方。

网关实现

这里介绍编码方式实现

HystrixObservableCommand.Setter getSetter() {
        HystrixCommandGroupKey groupKey = HystrixCommandGroupKey.Factory.asKey("group-accept");
        HystrixObservableCommand.Setter setter = HystrixObservableCommand.Setter.withGroupKey(groupKey);
        HystrixCommandKey commandKey = HystrixCommandKey.Factory.asKey("command-accept");

        setter.andCommandKey(commandKey);

        HystrixCommandProperties.Setter proertiesSetter = HystrixCommandProperties.Setter();
        proertiesSetter
                /* *
                 * 线程策略配置
                 */
                //设置线程模式 缺省 1000ms
                .withExecutionIsolationStrategy(HystrixCommandProperties.ExecutionIsolationStrategy.THREAD)
                //执行是否启用超时时间 缺省 true
                .withExecutionTimeoutEnabled(true)
                //使用线程隔离时,是否对命令执行超时的线程调用中断 缺省false
                .withExecutionIsolationThreadInterruptOnFutureCancel(false)
                //执行超时的时候是否要它中断 缺省 true
                .withExecutionIsolationThreadInterruptOnTimeout(true)
                //执行的超时时间 缺省 1000ms
                .withExecutionTimeoutInMilliseconds(2000)
                /* *
                 * 熔断策略
                 */
                //是否开启溶断 缺省 true
                .withCircuitBreakerEnabled(true)
                // 是否允许熔断器忽略错误,默认false, 不开启 ;
                // true,断路器强制进入“关闭”状态,它会接收所有请求。
                // 如果forceOpen属性为true,该属性不生效
                .withCircuitBreakerForceClosed(false)
                // 是否强制开启熔断器阻断所有请求, 默认为false
                // 为true时,所有请求都将被拒绝,直接到fallback.
                // 如果该属性设置为true,断路器将强制进入“打开”状态,
                // 它会拒绝所有请求。该属性优于forceClosed属性
                .withCircuitBreakerForceOpen(false)
                // 用来设置当断路器打开之后的休眠时间窗。
                // 休眠时间窗结束之后,会将断路器设置为“半开”状态,尝试熔断的请求命令,
                // 如果依然请求错误就将断路器继续设置为“打开”状态,如果成功,就设置为“关闭”状态
                // 熔断器默认工作时间,默认:5000豪秒.
                // 熔断器中断请求10秒后会进入半打开状态,放部分流量过去重试.
                .withCircuitBreakerSleepWindowInMilliseconds(5000)
                // 熔断器在整个统计时间内是否开启的阀值.
                // 在metricsRollingStatisticalWindowInMilliseconds(默认10s)内默认至少请求10次,
                // 熔断器才发挥起作用,9次熔断器都不起作用。
                .withCircuitBreakerRequestVolumeThreshold(100)
                // 该属性用来设置断路器打开的错误百分比条件。默认值为50.
                // 表示在滚动时间窗中,在请求值超过requestVolumeThreshold阈值的前提下,
                // 如果错误请求数百分比超过50,就把断路器设置为“打开”状态,否则就设置为“关闭”状态
                .withCircuitBreakerErrorThresholdPercentage(50);

        setter.andCommandPropertiesDefaults(proertiesSetter);

        return setter;
    }
@Bean
public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
 RouteLocatorBuilder.Builder routes = builder.routes();
 RouteLocatorBuilder.Builder serviceProvider = routes
  .route("accept",
   r -> r.method(HttpMethod.GET)
    .and()
    .path("/gateway-accept/**")
    .and()
    .header(HttpHeaders.CONTENT_TYPE, "application/json;charset=UTF-8")
    .filters(f -> {
     f.rewritePath("/gateway-accept/(?<path>.*)", "/${path}");
     f.requestRateLimiter(
      config -> config.setKeyResolver(new GenericAccessResolver())
       .setRateLimiter(redisRateLimiter()));
     f.hystrix(config -> config.setName("accept")
      .setFallbackUri("forward:/gateway-fallback")
      .setSetter(getSetter()));
     return f;
    })
    .uri("http://localhost:8888")
     );

 return serviceProvider.build();
}



在上面的代码中,主要做了3件事情:限流、熔断策略及降级方法配置

限流

  • 配置redis
spring:
  redis:
    database: 0
    host: 127.0.0.1
    port: 6379
    password:
    timeout: 1500
    lettuce:
      pool:
        max-active: 300 #连接池最大连接数(使用负值表示没有限制)
        max-idle: 10    #连接池中的最大空闲连接
        min-idle: 5     #连接池中的最小空闲连接
        max-wait: -1    #连接池最大阻塞等待时间(使用负值表示没有限制)



  • 自定义解析
/**
 * @description: 按照访问地址进行限流(也可以安装其他条件进行限流),具体可以看exchange.getRequest()的方法和属性
 **/
public class GenericAccessResolver implements KeyResolver {
    @Override
    public Mono<String> resolve(ServerWebExchange exchange) {
        return Mono.just(exchange.getRequest().getPath().value());
    }
}



  • 自定义限流配置
RedisRateLimiter redisRateLimiter() {
 //1000,1500对应replenishRate、burstCapacity
 return new RedisRateLimiter(1000, 1500);
}



  • 网关使用自定义限流器(网关使用代码实现)
@Bean
public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
    RouteLocatorBuilder.Builder routes = builder.routes();
    RouteLocatorBuilder.Builder serviceProvider = routes
        .route("accept",
               r -> r.method(HttpMethod.GET)
               .and()
               .path("/gateway-accept/**")
               .and()
               .header(HttpHeaders.CONTENT_TYPE, "application/json;charset=UTF-8")
               //.and()
               //.readBody(String.class, readBody -> true)
               .filters(f -> {
                   f.rewritePath("/gateway-accept/(?<path>.*)", "/${path}");
                   f.requestRateLimiter(config -> config.setKeyResolver(new GenericAccessResolver()).setRateLimiter(redisRateLimiter()));
                   return f;
               })
               .uri("http://localhost:8888")
              );

    return serviceProvider.build();
}
    • 测试

      • jmeter配置

引入 Gateway 网关,这些坑一定要学会避开!!!

      • 结果

引入 Gateway 网关,这些坑一定要学会避开!!!

  • 其他

    如果有多个路由,使用不同的限流策略,可以自定义KeyResolver和RedisRateLimiter, 在路由定义时加入

//基于ip限流
public class OtherAccessResolver implements KeyResolver {
    @Override
    public Mono<String> resolve(ServerWebExchange exchange) {
        return Mono.just(exchange.getRequest().getRemoteAddress().getHostName());
    }
}
RedisRateLimiter otherRedisRateLimiter() {
 //1000,1500对应replenishRate、burstCapacity
 return new RedisRateLimiter(100, 500);
}
@Bean
public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
 RouteLocatorBuilder.Builder routes = builder.routes();
 RouteLocatorBuilder.Builder serviceProvider = routes
  .route("accept",
   r -> r.method(HttpMethod.GET)
    .and()
    .path("/gateway-accept/**")
    .and()
    .header(HttpHeaders.CONTENT_TYPE, "application/json;charset=UTF-8")
    .filters(f -> {
     f.rewritePath("/gateway-accept/(?<path>.*)", "/${path}");
     f.requestRateLimiter(
      config -> config.setKeyResolver(new GenericAccessResolver())
       .setRateLimiter(redisRateLimiter()));
     f.hystrix(config -> config.setName("accept")
      .setFallbackUri("forward:/gateway-fallback")
      .setSetter(getSetter()));
     return f;
    })
    .uri("http://localhost:8888"))
        .route("sign",
   r -> r.method(HttpMethod.POST)
    .and()
    .path("/gateway-sign/**")
    .and()
    .header(HttpHeaders.CONTENT_TYPE, "application/json;charset=UTF-8")
    .filters(f -> {
     f.rewritePath("/gateway-sign/(?<path>.*)", "/${path}");
     f.requestRateLimiter(
      config -> config.setKeyResolver(new OtherAccessResolver())
       .setRateLimiter(otherRedisRateLimiter()));
     f.hystrix(config -> config.setName("sign")
      .setFallbackUri("forward:/gateway-fallback")
      .setSetter(getSetter()));
     return f;
    })
    .uri("http://localhost:7777")
     );

 return serviceProvider.build();
}



熔断策略

熔断策略主要是线程配置和熔断配置,上面已经说明很清楚了。在上篇文章中,为了解决网关调用后台服务Connection prematurely closed BEFORE response的问题,要设置后台服务线程的空闲时间和网关线程池线程的空闲时间,并让网关线程池线程的空闲时间小于后台服务的空闲时间

配置方法

spring:
  cloud:
    gateway:
      httpclient:
        pool:
            max-connections: 500
            max-idle-time: 10000



编码实现

翻阅Spring Cloud Gateway英文资料,知道路由提供一个metadata方法,可以设置路由的元数据(https://docs.spring.io/spring-cloud-gateway/docs/2.2.6.RELEASE/reference/html/#route-metadata-configuration),这些元数据在RouteMetadataUtils中定义:

package org.springframework.cloud.gateway.support;

public final class RouteMetadataUtils {
    public static final String RESPONSE_TIMEOUT_ATTR = "response-timeout";
    public static final String CONNECT_TIMEOUT_ATTR = "connect-timeout";

    private RouteMetadataUtils() {
        throw new AssertionError("Must not instantiate utility class.");
    }
}



其中没有我要的线程数量(max-connection)和空闲时间(max-idle-time)的设置,没有关系,自己加上去:

@Bean
public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
        RouteLocatorBuilder.Builder routes = builder.routes();
        RouteLocatorBuilder.Builder serviceProvider = routes
           .route("accept",
               r -> r.method(HttpMethod.GET)
                     .and()
                     .path("/gateway-accept/**")
                     .and()
                     .header(HttpHeaders.CONTENT_TYPE, "application/json;charset=UTF-8")
                     .filters(f -> {
                          f.rewritePath("/gateway-accept/(?<path>.*)", "/${path}");
                          f.requestRateLimiter(
                             config -> config.setKeyResolver(new GenericAccessResolver())
                                           .setRateLimiter(redisRateLimiter()));
                          f.hystrix(config -> config.setName("accept")
                                      .setFallbackUri("forward:/gateway-fallback")
                                      .setSetter(getSetter()));
                                return f;
                          })
                     .uri("http://localhost:8888")
                     .metadata("max-idle-time", 10000)  //网关调用后台线程空闲时间设置
                     .metadata("max-connections", 200)  //网关调用后台服务线程数量设置
          );

     return serviceProvider.build();
}



测试果然和yml配置一样有效果。

降级方法

降级方法本身没有什么特别,有一个问题需要注意,调用降级方法也是使用线程池的,缺省在HystrixThreadPoolProperties中定义:

public abstract class HystrixThreadPoolProperties {

    /* defaults */
    static int default_coreSize = 10;            // core size of thread pool
    static int default_maximumSize = 10;         // maximum size of thread pool
    static int default_keepAliveTimeMinutes = 1; // minutes to keep a thread alive
    static int default_maxQueueSize = -1;        // size of queue (this can't be dynamically changed so we use 'queueSizeRejectionThreshold' to artificially limit and reject)
                                                 // -1 turns it off and makes us use SynchronousQueue



错误

如果上面的限流设置比较大,比如1000,最大突发2000,网关调用后台服务发生熔断降级, 熔断后降级的方法调用太频繁,10个线程不够用,会导致以下500错误:

2021-02-01 14:29:45.076 ERROR 64868 --- [ioEventLoop-5-1] a.w.r.e.AbstractErrorWebExceptionHandler : [a0ed6911-18982]  500 Server Error for HTTP GET "/gateway-accept/test"

com.netflix.hystrix.exception.HystrixRuntimeException: command-accept fallback execution rejected.
 at com.netflix.hystrix.AbstractCommand.handleFallbackRejectionByEmittingError(AbstractCommand.java:1043) ~[hystrix-core-1.5.18.jar:1.5.18]
 Suppressed: reactor.core.publisher.FluxOnAssembly$OnAssemblyException:
Error has been observed at the following site(s):
 |_ checkpoint ⇢ org.springframework.cloud.gateway.filter.WeightCalculatorWebFilter [DefaultWebFilterChain]
 |_ checkpoint ⇢ HTTP GET "/gateway-accept/test" [ExceptionHandlingWebHandler]
com.netflix.hystrix.exception.HystrixRuntimeException: command-accept fallback execution rejected.
 at com.netflix.hystrix.AbstractCommand.handleFallbackRejectionByEmittingError(AbstractCommand.java:1043) ~[hystrix-core-1.5.18.jar:1.5.18]
 Suppressed: reactor.core.publisher.FluxOnAssembly$OnAssemblyException:
Error has been observed at the following site(s):
 |_ checkpoint ⇢ org.springframework.cloud.gateway.filter.WeightCalculatorWebFilter [DefaultWebFilterChain]
 |_ checkpoint ⇢ HTTP GET "/gateway-accept/test" [ExceptionHandlingWebHandler]

配置方法

所以要在yml中设置合适的调用降级方法的线程池, 合理的配置能够杜绝网关500错误的发生。

hystrix:
  threadpool:
    group-accept:  #代码里面设置的HystrixCommandGroupKey.Factory.asKey("group-accept")
      coreSize: 50 #并发执行的最大线程数,默认10
      maxQueueSize: 1500 #BlockingQueue的最大队列数
      #即使maxQueueSize没有达到,达到queueSizeRejectionThreshold该值后,请求也会被拒绝
      queueSizeRejectionThreshold: 1400

网关异常截获

上面的异常后,没有捕获异常直接返回前端500错误,一般情况下需要返回一个统一接口,比如:

@Data
@ToString
@EqualsAndHashCode
@Accessors(chain = true)
public class Result<T> implements Serializable {
    private Integer code;
    private String message;
    private T data;
    private String sign;

    public static final String SUCCESS = "成功";
    public static final String FAILURE = "失败";


    public Result(int code, String message) {
        this.code = code;
        this.message = message;
    }

    public Result(int code, String message, T data) {
        this.code = code;
        this.message = message;
        this.data = data;
    }
    public Result(int code, String message, T data, String sign) {
        this.code = code;
        this.message = message;
        this.data = data;
        this.sign = sign;
    }

    public static Result<Object> success() {
        return new Result<Object>(200, SUCCESS);
    }
    public static Result<Object> success(Object data) {
        return new Result<Object>(200, SUCCESS, data);
    }
    public static Result<Object> success(Object data, String sign) {
        return new Result<Object>(200, SUCCESS, data, sign);
    }
    public static Result<Object> failure() {
        return new Result<Object>(400, FAILURE);
    }
    public static Result<Object> failure(Object data) {
        return new Result<Object>(400, FAILURE, data);
    }
    public static Result<Object> failure(Object data, String sign) {
        return new Result<Object>(400, FAILURE, data, sign);
    }


}



创建GlobalExceptionConfiguration 实现ErrorWebExceptionHandler(这一段是来者网友提供的)

@Slf4j
@Order(-1)
@Component
@RequiredArgsConstructor
public class GlobalExceptionConfiguration implements ErrorWebExceptionHandler {
    private final ObjectMapper objectMapper;

    @Override
    public Mono<Void> handle(ServerWebExchange exchange, Throwable ex) {
        ServerHttpResponse response = exchange.getResponse();

        if (response.isCommitted()) {
            return Mono.error(ex);
        }

        response.getHeaders().setContentType(MediaType.APPLICATION_JSON_UTF8);
        if (ex instanceof ResponseStatusException) {
            response.setStatusCode(((ResponseStatusException) ex).getStatus());
        }

        return response
                .writeWith(Mono.fromSupplier(() -> {
                    DataBufferFactory bufferFactory = response.bufferFactory();
                    try {
                        return bufferFactory.wrap(objectMapper.writeValueAsBytes(Result.failure(ex.getMessage())));
                    } catch (JsonProcessingException e) {
                        log.warn("Error writing response", ex);
                        return bufferFactory.wrap(new byte[0]);
                    }
                }));
    }
}



这样,就会把网关异常统一包装在接口中返回:如:

引入 Gateway 网关,这些坑一定要学会避开!!!

后台日志已经没有之前的错误日志了。

编码实现,没找到

由于Spring Cloud Gateway 中的 Hystrix采用的是HystrixObservableCommand.Setter, 没有采用 HystrixCommand.Setter, 在 HystrixCommand.Setter中是可以编码实现线程池配置的, 但是在HystrixObservableCommand.Setter没有提供:

final public static class Setter {
        protected final HystrixCommandGroupKey groupKey;
        protected HystrixCommandKey commandKey;
        protected HystrixThreadPoolKey threadPoolKey;  //有属性但是没有set方法
        protected HystrixCommandProperties.Setter commandPropertiesDefaults;
        protected HystrixThreadPoolProperties.Setter threadPoolPropertiesDefaults; //有属性没有set方法

        protected Setter(HystrixCommandGroupKey groupKey) {
            this.groupKey = groupKey;
            // default to using SEMAPHORE for ObservableCommand
            commandPropertiesDefaults = setDefaults(HystrixCommandProperties.Setter());
        }

        public static Setter withGroupKey(HystrixCommandGroupKey groupKey) {
            return new Setter(groupKey);
        }

        public Setter andCommandKey(HystrixCommandKey commandKey) {
            this.commandKey = commandKey;
            return this;
        }

        public Setter andCommandPropertiesDefaults(HystrixCommandProperties.Setter commandPropertiesDefaults) {
            this.commandPropertiesDefaults = setDefaults(commandPropertiesDefaults);
            return this;
        }

        private HystrixCommandProperties.Setter setDefaults(HystrixCommandProperties.Setter commandPropertiesDefaults) {
            if (commandPropertiesDefaults.getExecutionIsolationStrategy() == null) {
                // default to using SEMAPHORE for ObservableCommand if the user didn't set it
                commandPropertiesDefaults.withExecutionIsolationStrategy(ExecutionIsolationStrategy.SEMAPHORE);
            }
            return commandPropertiesDefaults;
        }
    }



由于本人水平有限,没有找到Setter中设置HystrixThreadPoolKeyHystrixThreadPoolProperties.Setter的方法,所以只能在yml中配置。有知道的同学告诉我一声,不胜感激。

总结

所以在Spring Cloud Gateway网关的配置中,需要综合考虑限流大小、网关调用后台连接池设置大小、后台服务的连接池以及空闲时间,包括网关调用降级方法的线程池配置,都需要在压测中调整到一个合理的配置,才能发挥最大的功效。

本人水平有限,跟深入的研究还在继续,如果文章有表达错误或者不周,请大家指正,谢谢!


开心洋葱 , 版权所有丨如未注明 , 均为原创丨未经授权请勿修改 , 转载请注明引入 Gateway 网关,这些坑一定要学会避开!!!
喜欢 (0)

您必须 登录 才能发表评论!

加载中……
