ES数据库高可用配置

Linux 坚果Leo 2223次浏览 0个评论

1、ES高可用架构图

ES数据库高可用配置

ES数据库最好的高可用集群部署架构为:
三台服务器做master节点、三台服务器作为data节点(存储资源要大)、三台做ingest节点(用于数据转换,可以提高ES查询效率)

2、创建ES用户组

Elasticsearch不能在 root 用户下启动,我们需要在三台机器上分创建一个普通用户# 创建elastic用户

useradd elastic

设置用户密码

passwd elastic

测试服务器密码设置的是

abc123!@#

切换到elastic用户

su elastic

分别在三台机器上的 /home/elastic/ 目录下分别创建data、logs文件夹。

cd /home/elastic/
mkdir data

mkdir logs在生产环境下我们要把Elasticsearch生成的索引文件数据存放到自定义的目录下
data:存储Elasticsearch索引文件数据
logs:存储日志文件
3.系统设置。
使用root用户分别在三台服务器上增加 /etc/sysctl.conf 配置
添加内容为

vm.max_map_count = 655300

接着输入如下命令让配置生效:

sysctl -p

解锁文件限制,增加 /etc/security/limits.conf 配置

* soft nofile 65535
* hard nofile 65535
* soft nofile 65535
* hard nofile 65535

4、配置Elasticsearch

首先我们将下载好的elasticsearch-7.6.2-linux-x86_64.tar.gz压缩包通过elastic普通用户,上传到三台服务器集群的/home/elastic目录下,解压

tar -zxvf elasticsearch-7.9.0-linux-x86_64.tar.gz

如果是root用户,上传压缩包解压后,需要修改elastic 目录的拥有者

cd /home/
chown -R elastic elastic

解压完成后ll查看目录
su elastic一定要切换用户,切记!切记!
分别修改elasticsearch.yml配置文件

vi /home/elastic/elasticsearch-7.9.0/config/elasticsearch.yml
cluster.name: data-cluster
node.name: "data-es-05"
#node.data: false

# Indexing & Cache config
index.number_of_shards: 5
index.number_of_replicas: 1
index.cache.field.type: soft
index.cache.field.expire: 10m
index.cache.query.enable: true
indices.cache.query.size: 2%
indices.fielddata.cache.size: 35%
indices.fielddata.cache.expire: 10m
index.search.slowlog.level: INFO
#indices.recovery.max_size_per_sec: 1gb
index.merge.scheduler.max_thread_count: 2    # Only for spinning media.

# Refresh config
index.refresh_interval: 300s

# Translog config
index.translog.flush_threshold_ops:  100000

# Paths config
path.data: /data/esData
path.plugins: /usr/share/elasticsearch/plugins

# Network And HTTP
network.bind_host: 10.0.126.203
network.publish_host: 10.0.126.203
transport.tcp.port: 9300
transport.tcp.compress: true
http.port: 9200

# Discovery
discovery.zen.minimum_master_nodes: 1
discovery.zen.ping.timeout: 10s
discovery.zen.ping.multicast.enabled: false
discovery.zen.ping.unicast.hosts: ["10.0.32.3:9300", "10.0.4.37:9300", "10.0.40.159:9300", "10.0.107.116:9300" , "10.0.126.203:9300"]
    配置文件位于%ES_HOME%/config/elasticsearch.yml文件中,用Editplus打开它,你便可以进行配置。
        所有的配置都可以使用环境变量,例如:
   node.rack: ${RACK_ENV_VAR}   表示环境变量中有一个RACK_ENV_VAR变量。
        下面列举一下elasticsearch的可配置项:
        1. 集群名称,默认为elasticsearch:
    cluster.name: elasticsearch
        2. 节点名称,es启动时会自动创建节点名称,但你也可进行配置:
    node.name: "Franz Kafka"
        3. 是否作为主节点,每个节点都可以被配置成为主节点,默认值为true:
    node.master: true
        4. 是否存储数据,即存储索引片段,默认值为true:
    node.data: true
         master和data同时配置会产生一些奇异的效果:
        1) 当master为false,而data为true时,会对该节点产生严重负荷;
        2) 当master为true,而data为false时,该节点作为一个协调者;
        3) 当master为false,data也为false时,该节点就变成了一个负载均衡器。
        你可以通过连接http://localhost:9200/_cluster/health或者http://localhost:9200/_cluster/nodes,或者使用插件http://github.com/lukas-vlcek/bigdesk或http://mobz.github.com/elasticsearch-head来查看集群状态。
        5. 每个节点都可以定义一些与之关联的通用属性,用于后期集群进行碎片分配时的过滤:
    node.rack: rack314
        6. 默认情况下,多个节点可以在同一个安装路径启动,如果你想让你的es只启动一个节点,可以进行如下设置:
    node.max_local_storage_nodes: 1
        7. 设置一个索引的碎片数量,默认值为5:
    index.number_of_shards: 5
        8. 设置一个索引可被复制的数量,默认值为1:
    index.number_of_replicas: 1
           当你想要禁用公布式时,你可以进行如下设置:
    index.number_of_shards: 1
    index.number_of_replicas: 0
         这两个属性的设置直接影响集群中索引和搜索操作的执行。假设你有足够的机器来持有碎片和复制品,那么可以按如下规则设置这两个值:
           1) 拥有更多的碎片可以提升索引执行能力,并允许通过机器分发一个大型的索引;
           2) 拥有更多的复制器能够提升搜索执行能力以及集群能力。
           对于一个索引来说,number_of_shards只能设置一次,而number_of_replicas可以使用索引更新设置API在任何时候被增加或者减少。
           ElasticSearch关注加载均衡、迁移、从节点聚集结果等等。可以尝试多种设计来完成这些功能。
           可以连接http://localhost:9200/A/_status来检测索引的状态。
        9. 配置文件所在的位置,即elasticsearch.yml和logging.yml所在的位置:
           path.conf: /path/to/conf
        10. 分配给当前节点的索引数据所在的位置:
    path.data: /path/to/data
           可以可选择的包含一个以上的位置,使得数据在文件级别跨越位置,这样在创建时就有更多的自由路径,如:
    path.data: /path/to/data1,/path/to/data2
        11. 临时文件位置:
           path.work: /path/to/work
        12. 日志文件所在位置:
    path.logs: /path/to/logs
        13. 插件安装位置:
    path.plugins: /path/to/plugins
        14. 插件托管位置,若列表中的某一个插件未安装,则节点无法启动:
    plugin.mandatory: mapper-attachments,lang-groovy
        15. JVM开始交换时,ElasticSearch表现并不好:你需要保障JVM不进行交换,可以将bootstrap.mlockall设置为true禁止交换:
    bootstrap.mlockall: true
           请确保ES_MIN_MEM和ES_MAX_MEM的值是一样的,并且能够为ElasticSearch分配足够的内在,并为系统操作保留足够的内存。
        16. 默认情况下,ElasticSearch使用0.0.0.0地址,并为http传输开启9200-9300端口,为节点到节点的通信开启9300-9400端口,也可以自行设置IP地址:
            network.bind_host: 192.168.0.1
        17. publish_host设置其他节点连接此节点的地址,如果不设置的话,则自动获取,publish_host的地址必须为真实地址:
            network.publish_host: 192.168.0.1
        18. bind_host和publish_host可以一起设置:
     network.host: 192.168.0.1
        19. 可以定制该节点与其他节点交互的端口:
    transport.tcp.port: 9300
        20. 节点间交互时,可以设置是否压缩,转为为不压缩:
    transport.tcp.compress: true
        21. 可以为Http传输监听定制端口:
    http.port: 9200
        22. 设置内容的最大长度:
    http.max_content_length: 100mb
        23. 禁止HTTP
    http.enabled: false
        24. 网关允许在所有集群重启后持有集群状态,集群状态的变更都会被保存下来,当第一次启用集群时,可以从网关中读取到状态,默认网关类型(也是推荐的)是local:
    gateway.type: local
        25. 允许在N个节点启动后恢复过程:
    gateway.recover_after_nodes: 1
        26. 设置初始化恢复过程的超时时间:
    gateway.recover_after_time: 5m
        27. 设置该集群中可存在的节点上限:
    gateway.expected_nodes: 2
        28. 设置一个节点的并发数量,有两种情况,一种是在初始复苏过程中:
    cluster.routing.allocation.node_initial_primaries_recoveries: 4
           另一种是在添加、删除节点及调整时:
    cluster.routing.allocation.node_concurrent_recoveries: 2
        29. 设置复苏时的吞吐量,默认情况下是无限的:
    indices.recovery.max_size_per_sec: 0
        30. 设置从对等节点恢复片段时打开的流的数量上限:
    indices.recovery.concurrent_streams: 5
        31. 设置一个集群中主节点的数量,当多于三个节点时,该值可在2-4之间:
    discovery.zen.minimum_master_nodes: 1
        32. 设置ping其他节点时的超时时间,网络比较慢时可将该值设大:
    discovery.zen.ping.timeout: 3s
    http://elasticsearch.org/guide/reference/modules/discovery/zen.html上有更多关于discovery的设置。
        33. 禁止当前节点发现多个集群节点,默认值为true:
    discovery.zen.ping.multicast.enabled: false
        34. 设置新节点被启动时能够发现的主节点列表(主要用于不同网段机器连接):

    discovery.zen.ping.unicast.hosts: ["host1", "host2:port", "host3[portX-portY]"]

       35.设置是否可以通过正则或者_all删除或者关闭索引

3、Elasticsearch配置优化

1、skywalking的elasticsearch配置优化

#bulkActions默认1000次请求批量写入一次改到4000次。
bulkActions: ${SW_STORAGE_ES_BULK_ACTIONS:4000} # Execute the bulk every 1000 requests

#flushInterval每10秒刷新一次堆改为每30秒刷新。
flushInterval: ${SW_STORAGE_ES_FLUSH_INTERVAL:30} # flush the bulk every 10 seconds whatever the number of requests

#concurrentRequests并发请求的数量由2改为4。
concurrentRequests: ${SW_STORAGE_ES_CONCURRENT_REQUESTS:4} # the number of concurrent requests

#metadataQueryMaxSize查询的最大数量由5000改为8000。
metadataQueryMaxSize: ${SW_STORAGE_ES_QUERY_MAX_SIZE:8000}

2、elasticsearch内置参数优化

index.merge.scheduler.max_thread_count# 索引 merge 最大线程数
index.refresh_interval#index 刷新间隔
index.translog.durability# 这个可以异步写硬盘,增大写的速度
index.translog.sync_interval #translog 间隔时间
curl -H "Content-Type: application/json" -u -key elastic:elastic -X PUT 'http://192.168.40.7:9200/_all/_settings?preserve_existing=true' -d '{
  "index.merge.scheduler.max_thread_count" : "1",
  "index.refresh_interval" : "30s",
  "index.translog.durability" : "async",
  "index.translog.sync_interval" : "120s"
}'

3、ES堆内存优化(根据服务器的硬件资源配置合理修改参数,一般8C 64G 堆内存最好选用内存的二分之一,也就是32G)

# Xms represents the initial size of total heap space
# Xmx represents the maximum size of total heap space

-Xms32g
-Xmx32g

################################################################
## Expert settings
################################################################

4、ES分片数优化(ES7.2之后,分片数默认为3000,可以对max_shards_per_node进行修改)

curl -k -u elastic:abc123!@# -H "Content-Type:application/json" -X PUT -d '{"transient": {"cluster": {"max_shards_per_node":12000}}}' http://ip地址:9200/_cluster/settings

5、验证ES高可用配置

http://localhost:9200/_all/_settings
